NeedThese, Your Tech-ucation Partner Your quote

Products › Data Capture / Point of Sale

Zebra - Sourcing

Zebra ZD620 label printer Direct thermal 203 x 203 DPI 203 mm/sec Wired & Wireless Ethernet LAN Bluetooth

Part number ZD62042-D01F00EZ

ZEBRA ZD620D DIRECT THERMAL DESKTOP PRINTER

  • Direct thermal
  • 203 x 203 DPI
  • Maximum printing width: 10.4 cm Print speed: 203 mm/sec
  • Built-in barcodes: 1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
  • Connectivity technology: Wired & Wireless
  • USB port Ethernet LAN Bluetooth 4.1
  • 1.6 kg
Manufacturer
Zebra - Sourcing
Part number
ZD62042-D01F00EZ
Condition
New
Category
Data Capture / Point of Sale › Auto Id Printers
1GPA category
Hardware

Overview

POWERFUL DOESN'T NEED TO BE COMPLICATED

When print quality, productivity, application flexibility and management simplicity matter, the Zebra ZD620 delivers. As the next generation in Zebra’s desktop printer line, the ZD620 replaces Zebra’s popular GX Series and ZD500 printers, rising above conventional desktop printers with premium print quality and state of the art features. Available in both direct thermal and thermal transfer models, the ZD620 meets a wide variety of application requirements. It offers the most standard features of any Zebra desktop printer, including an optional 10-button user interface with a color LCD that takes all the guesswork out of printer setup and status. The ZD620 runs Link-OS and is supported by our powerful Print DNA suite of applications, utilities and developer tools that deliver a superior printing experience through better performance, simplified remote manageability and easier integration. The Zebra ZD620 — delivering the powerful print speed, print quality and printer manageability you need to keep your operations moving forward.

PREMIER PRINTING PERFORMANCE

The ZD620 delivers maximum printer throughput and productivity with best-in-class print speeds.

EASE-OF-USE

A three-button interface with five LED status icons or an optional 10-button interface with color LCD display makes it easy to setup, configure or restore printer availability before productivity is impacted.

DEPLOYMENT AND APPLICATION FLEXIBILITY

The same label formats and applications you are using today plus comprehensive connectivity options enable you to connect to your existing wired or wireless network, or directly to any PC. The ZD620 runs Link-OS and is supported by our powerful Print DNA suite of applications, utilities and developer tools for better performance, simplified remote manageability and easier integration.

Specifications

Printing
Print technologyDirect thermal
Maximum resolution203 x 203 DPI
Print speed203 mm/sec
Maximum printing width10.4 cm
Paper handling
Maximum label length0.991 m
Maximum roll diameter12.7 cm
Media thickness0.08 - 0.1905 mm
Ports & interfaces
Connectivity technologyWired & Wireless
Ethernet LANYes
Wi-FiNo
BluetoothYes
Bluetooth version4.1
USB portYes
USB 2.0 ports quantity1
RS-232 ports1
Performance
Page description languagesEPL2, XML, ZBI, ZPL II
Internal memory256 MB
Flash memory512 MB
Built-in barcodes1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Number of fonts16
Design
Product colourBlack, Grey
Built-in displayNo
DisplayNo
Power
AC input voltage100 - 240 V
AC input frequency50-60 Hz
System requirements
Windows operating systems supportedYes
Mobile operating systems supportedAndroid, iOS
Operational conditions
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 95%
Operating temperature (T-T)4.4 - 41 °C
Storage temperature (T-T)-40 - 60 °C
Weight & dimensions
Width177 mm
Depth221 mm
Height151 mm
Weight1.6 kg
Technical details
Sustainability certificatesENERGY STAR
Other features
Clock functionYes

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
