Viewsonic VB-WIFI-004 network card WLAN
Part number VB-WIFI-004
USB WI-FI MODULE FOR IFP105S IFP33 IFP32 IFP32-2
- Wireless
- USB WLAN
- Wi-Fi Dual-band (2.4 GHz / 5 GHz)
- Component for: Interactive whiteboard
- Manufacturer
- ViewSonic
- Part number
- VB-WIFI-004
- Condition
- New
- Category
- Network Devices › Wireless Networking
- 1GPA category
- Hardware
Overview
The ViewSonic VB-WIFI-004 wireless module delivers fast internet connection for the ViewBoard®32-2 series. It supports dual-frequency 2.4GHz and 5GHz bandwidth, along with the 802.11AX standard.
Faster Connections
An optional Wi-Fi module for the ViewBoards 32-2 Series facilitates smooth lesson flow and drives a more interactive discussion in the classroom.
Dual Band Wireless Support
Supported by both 2.4 GHz and 5 GHz dual-band wireless transmission, teachers can smoothly stream multimedia content such as videos and images without any delays and create higher student engagement. The 2.4 GHz connection travels farther at lower speeds, while 5 GHz frequencies provide faster speeds at a shorter range.
Specifications
| Connectivity technology | Wireless |
|---|---|
| Host interface | USB |
| Interface | WLAN |
| USB ports quantity | 1 |
| Wi-Fi | Yes |
|---|---|
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Component for | Interactive whiteboard |
|---|---|
| Product colour | Black |
| Antenna | Yes |
| Antenna design | Internal |
| Certification | CE (EMC-safety), CE-RED, WPC, LVD, RCM, FCC ID, IC ID |
| Power consumption (typical) | 5 W |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width | 208 mm |
|---|---|
| Depth | 30 mm |
| Height | 20 mm |
| Weight | 85 g |
| Package width | 212 mm |
|---|---|
| Package depth | 35 mm |
| Package height | 25 mm |
| Package weight | 102 g |
| Harmonized System (HS) code | 8517620000 |
|---|---|
| Pallet gross width | 175 cm |
| Pallet gross length | 114 cm |
| Pallet gross height | 85.7 cm |
| Products per master (outer) case | 100 pc(s) |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
