Products › Imaging Devices

ViewSonic

Viewsonic VB-VIS-002 document camera White CMOS USB 2.0

Part number VB-VIS-002

8 MEGAPIXEL DOCUMENT CAM W/ LED BRIGHTNESS AFBTNS TYPEA CBL WHT

  • ADJUSTABLE ARM
  • CONVENIENT PRESETS
  • CROSS-PLATFORM SUPPORT
Manufacturer
ViewSonic
Part number
VB-VIS-002
Condition
New
Category
Imaging Devices › Cameras
1GPA category
Hardware

Overview

The ViewSonic® VB-VIS-002 is an easy-to-use, plug-and-play USB document camera that is an essential tool for hybrid education setups. Compatible with myViewBoard™ software, this document camera can deliver a live feed to the myViewBoard digital canvas so both remote and in-class students can view annotations. The VB-VIS-002 has an 8-megapixel image sensor that delivers vivid colors and images, while an adjustable arm makes for easy image capture.

WORKS WITH MYVIEWBOARD

With a live camera feed on the myViewBoard™ whiteboard canvas, educators can capture screenshots and annotations and easily share them with students in any location.

8-MEGAPIXEL IMAGE SENSOR

An 8-megapixel image sensor supports up to 3264x2448 resolution for crystal clear images and videos.

CROSS-PLATFORM SUPPORT

Plug-and-play support for Windows, MacOS, and Chrome OS.

EASY AUTO-FOCUS

An intelligent auto-focus feature automatically adjusts the camera lens to ensure razor-sharp images and quick setup every time.

8X DIGITAL ZOOM

Powerful 8x digital zoom enables users to quickly enlarge screen images for more effective and immersive lessons (vDocCam software required).

CONVENIENT PRESETS

Easy-access buttons allow for quick adjustments such as focus, brightness and LED lighting.

ADJUSTABLE ARM

An ultra-flexible arm provides quick and easy camera adjustments for better image capture.

Specifications

Camera
Effective sensor resolution8 MP
Sensor typeCMOS
Supported graphics resolutions1200 x 1600, 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2592 x 1944, 3264 x 2448
HD type4K Ultra HD
Ports & interfaces
InterfaceUSB 2.0
USB connector typeUSB Type-A
USB 2.0 ports quantity1
Technical details
Product colourWhite
Power
Power supply typeUSB
USB poweredYes
Operating voltage5 V
Operational conditions
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 80%
Weight & dimensions
Width255 mm
Depth85 mm
Height70 mm
Weight400 g
Packaging data
Package width289 mm
Package depth115 mm
Package height83 mm
Package weight600 g
Packaging content
User guideYes
Cables includedUSB
Logistics data
Pallet gross length100 cm
Pallet gross width120 cm
Pallet gross height176.4 cm
Products per master (outer) case12 pc(s)

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
