ViewSonic TD2430
View 1 View 2 View 3 View 4 View 5 View 6 View 7 View 8
ViewSonic

Viewsonic TD2430 computer monitor 59.9 cm (23.6") 1920 x 1080 pixels Full HD LCD Touchscreen Multi-user Black

Part number TD2430

24 (23.6 VIEWABLE) FULL HD 10-POINT TOUCH DISPLAY

  • 59.9 cm (23.6") Black
  • Built-in speaker(s)
  • USB upstream port type: USB Type-B HDMI HDMI version: 1.4 DisplayPorts quantity: 1 DisplayPort version: 1.2
  • Screen shape: Flat
  • Maximum refresh rate: 76 Hz Response time: 5 ms
  • 1920 x 1080 pixels Full HD Panel type: VA
  • Energy efficiency class (SDR): E ENERGY STAR, ErP CE, REACH, RoHS
Manufacturer
ViewSonic
Part number
TD2430
Condition
New
Category
Displays › Touchscreen Monitors
1GPA category
Hardware

Overview

- 10-point Projected Capacitive Touch

- SuperClear® MVA-type panel technology

- Frameless Design

- Versatile Connectivity

- Durable, Scratch-resistant Screen

Laid flat or angled for customized comfort, this display delivers touchscreen versatility to the max. Offering fantastic flexibility for retail, education, or business settings, the ViewSonic® TD2430 is a 24” (23.6” viewable) Full HD display with 10-point multi-touch functionality. Delivering adjustable positioning, wide-angle viewing, and a durable design, the TD2430 has everything to accommodate your unique needs. Adding even more convenience, cross-compatibility with a wide range of operating systems includes Windows 10, and certain Android and Linux versions.* With a sleek edge-to-edge screen and frameless bezel, this intuitive touchscreen performs like your favorite tablet or smartphone to deliver a highly accurate, ultra-responsive touch experience ideal for interactivity in public environments, kiosk and wayfinding applications, classroom settings, and more.

*Supports Windows 7/8/10, Linux 2.6.38 or later, and Android 4.0 or later.

Specifications

Display
Display diagonal59.9 cm (23.6")
Display resolution1920 x 1080 pixels
HD typeFull HD
Native aspect ratio16:9
Display technologyLCD
Panel typeVA
TouchscreenYes
Touchscreen typeMulti-user
Touchscreen technologyProjected capacitive system
Touch technologyMulti-touch
Number of simultaneous touchpoints10
Display brightness200 cd/m²
Response time5 ms
Screen shapeFlat
Contrast ratio (typical)3000:1
Contrast ratio (dynamic)50000000:1
Maximum refresh rate76 Hz
Viewing angle, horizontal178°
Viewing angle, vertical178°
Pixel pitch0.2715 x 0.2715 mm
Horizontal scan range24 - 82 kHz
Vertical scan range50 - 75 Hz
Display diagonal (metric)60 cm
Performance
NVIDIA G-SYNCNo
AMD FreeSyncNo
Windows operating systems supportedWindows 10, Windows 7, Windows 8
Mac operating systems supportedYes
Linux operating systems supportedYes
Other operating systems supportedAndroid
Multimedia
Number of speakers2
RMS rated power5 W
Built-in speaker(s)Yes
Built-in microphoneNo
Built-in cameraNo
Design
Product colourBlack
Ports & interfaces
Built-in USB hubYes
USB hub version3.2 Gen 1 (3.1 Gen 1)
USB upstream port typeUSB Type-B
Number of upstream ports1
Number of USB Type-B upstream ports quantity1
USB Type-A downstream ports quantity2
VGA (D-Sub) ports quantity1
HDMIYes
HDMI ports quantity1
HDMI version1.4
DisplayPorts quantity1
DisplayPort version1.2
Headphone outYes
Headphone outputs1
Ergonomics
VESA mountingYes
Panel mounting interface100 x 100 mm
Wall mountableYes
Tilt adjustmentYes
Tilt angle range20 - 53°
Power
Energy efficiency class (SDR)E
Energy efficiency class (HDR)Not available
Energy consumption (SDR) per 1000 hours15 kWh
Power consumption (typical)25 W
Power consumption (standby)0.5 W
Power consumption (off)0.3 W
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power supply typeAC
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)20 - 90%
Storage relative humidity (H-H)5 - 90%
Weight & dimensions
Width (with stand)573 mm
Depth (with stand)47 mm
Height (with stand)353 mm
Weight (with stand)5.51 kg
Packaging data
Package width643 mm
Package depth140 mm
Package height435 mm
Package weight7.1 kg
Packaging content
Cables includedAC, Audio (3.5mm), HDMI, USB
Sustainability
Sustainability certificatesENERGY STAR, ErP
Other features
Display viewable area (HxV)521.28 x 293.22 mm
Mobile operating systems supportedAndroid
Weight5.5 kg
Compliance certificatesCE, REACH, RoHS
CertificationcTUVus, FCC-B, ICES003, Energy Star 8.0, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, RCM, GEMS, CCC, China RoHS, China Energy Label, CECP
Technical details
Native refresh rate60 Hz
Logistics data
Products per master (outer) case1 pc(s)
Pallet gross width120 cm
Pallet gross length100 cm
Pallet gross height189 cm
Harmonized System (HS) code8528521000

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
