Overview
Introducing the LS901-4K from ViewSonic’s Luminous Superior Series, tailored for expansive venue displays. Featuring 5,500 ANSI lumens of brightness and high native contrast provided by a 0.65” DMD chip through DLP technology, it delivers stunning 4K UHD visuals on screens larger than 100 inches. Perfect for museums and educational institutions, the LS901-4K’s ultra-high resolution with HDR/HLG support ensures every detail is vivid and clear, enhancing viewer engagement. With 21:9 aspect ratio support, the LS901-4K is also an ideal choice for Microsoft Teams Rooms. Its 1.7x optical zoom allows for a flexible setup to suit various installation needs, and the vertical lens shift and H/V keystone adjustment make the process a breeze. Additionally, portrait mode and 360° projection capabilities cater to more advanced requirements. Comprehensive LAN control ensures seamless integration into corporate networks. Employing advanced 3rd generation laser phosphor technology, the LS901-4K boasts a remarkable 30,000-hour lifespan, reducing maintenance costs for both business and educational institutions.
Specifications
Projector
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
|---|
| Projection distance | 0.8 - 13.55 m |
|---|
| Projector brightness | 5500 ANSI lumens |
|---|
| Projector native resolution | UHD 4K (3840x2160) |
|---|
| Contrast ratio (typical) | 3000000:1 |
|---|
| Native aspect ratio | 16:9 |
|---|
| Number of colours | 1.07 billion colours |
|---|
| Horizontal scan range | 15 - 255 kHz |
|---|
| Vertical scan range | 23 - 240 Hz |
|---|
| Keystone correction, horizontal | -30 - 30° |
|---|
| Keystone correction, vertical | -30 - 30° |
|---|
Light source
| Service life of light source | 20000 h |
|---|
| Service life of light source (economic mode) | 30000 h |
|---|
Lens system
| Focal length range | 17.63 - 27.9 mm |
|---|
| Aperture range (F-F) | 2.3 - 3 |
|---|
| Zoom capability | Yes |
|---|
| Vertical lens shift range | -21 - 0% |
|---|
| Offset | 154% |
|---|
Ports & interfaces
| USB 2.0 ports quantity | 2 |
|---|
| Audio (L/R) out | 1 |
|---|
| Serial interface type | RS-232 |
|---|
| HDMI ports quantity | 2 |
|---|
| AC (power) in | Yes |
|---|
Network
| Ethernet LAN | Yes |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
|---|
Features
| Noise level (economic mode) | 25 dB |
|---|
| Noise level | 31 dB |
|---|
Multimedia
| Built-in speaker(s) | Yes |
|---|
| RMS rated power | 30 W |
|---|
| Number of built-in speakers | 2 |
|---|
Design
| Market positioning | Education |
|---|
| Product type | Standard throw projector |
|---|
| Product colour | White |
|---|
| LED indicators | Yes |
|---|
Display
| Built-in display | No |
|---|
Power
| Power source | AC |
|---|
| Power consumption (typical) | 245 W |
|---|
| Power consumption (standby) | 0.5 W |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
Weight & dimensions
| Width | 337 mm |
|---|
| Depth | 280 mm |
|---|
| Height | 132 mm |
|---|
| Weight | 4.85 kg |
|---|
| Package width | 496 mm |
|---|
| Package depth | 195 mm |
|---|
| Package height | 387 mm |
|---|
| Package weight | 6.8 kg |
|---|
Packaging content
| Remote control included | Yes |
|---|
| Manual | Yes |
|---|
Logistics data
| Pallet gross length | 102 cm |
|---|
| Pallet gross width | 122 cm |
|---|
| Pallet gross height | 2.06 m |
|---|
| Products per master (outer) case | 1 pc(s) |
|---|
| Harmonized System (HS) code | 8528620000 |
|---|
