Overview
The CDE92UW is an ultrawide 92” digital display delivering stunning image performance with 5K resolution. Designed for both corporate and commercial use, it features a 21:9 aspect ratio, providing 33% more screen real estate than a comparable 16:9 display, making it ideal for Microsoft Teams Rooms and Front Row Mode. Powered by an octa-core SoC running Android 13, the CDE92UW enables seamless multitasking with a USB-C port that delivers 100W and multiple wireless content sharing options. It also supports daisy chaining and comes pre-installed with ViewSonic Manager, a centralized platform that streamlines corporate communication and enhances operational efficiency.
Specifications
Display
| Display diagonal | 2.34 m (92") |
|---|
| Display brightness | 500 cd/m² |
|---|
| Display number of colours | 1.07 billion colours |
|---|
| Display resolution | 5120 x 2160 pixels |
|---|
| Anti-glare screen | Yes |
|---|
| Panel type | IPS |
|---|
| LED backlight | Yes |
|---|
| LED backlighting type | Direct-LED |
|---|
| Native aspect ratio | 21:9 |
|---|
| Contrast ratio (typical) | 5000:1 |
|---|
| Response time | 6.5 ms |
|---|
| Viewing angle, horizontal | 178° |
|---|
| Viewing angle, vertical | 178° |
|---|
| Working area | 2141.952 x 903.636 mm |
|---|
| Haze rate | 25% |
|---|
| Hardness | 3H |
|---|
Computer system
| Operating system installed | Android |
|---|
| Operating system version | 13 |
|---|
| Built-in processor | Yes |
|---|
| Processor architecture | ARM Cortex A76 + ARM Cortex A55 |
|---|
| Processor cores | 8 |
|---|
| Maximum internal memory | 128 GB |
|---|
| RAM capacity | 8 GB |
|---|
| RAM type | DDR4 |
|---|
Audio
| Built-in speaker(s) | Yes |
|---|
| Number of built-in speakers | 2 |
|---|
| Speaker power | 20 W |
|---|
| Built-in subwoofer | Yes |
|---|
| Subwoofer RMS power | 2 W |
|---|
Projector
| Built-in projector | No |
|---|
Ports & interfaces
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 4 |
|---|
| HDMI ports quantity | 4 |
|---|
| HDMI output ports quantity | 1 |
|---|
| DisplayPorts quantity | 1 |
|---|
| Line-in | Yes |
|---|
| Line-out | Yes |
|---|
| RS-232 ports | 1 |
|---|
Ergonomics
| Product colour | Black |
|---|
| VESA mounting | Yes |
|---|
| Panel mounting interface | 800 x 600 mm |
|---|
Weight & dimensions
| Width | 2182 mm |
|---|
| Depth | 85.2 mm |
|---|
| Height | 943.8 mm |
|---|
| Weight | 43.4 kg |
|---|
Packaging data
| Package width | 2360 mm |
|---|
| Package depth | 225 mm |
|---|
| Package height | 1072 mm |
|---|
| Package weight | 63 kg |
|---|
| Quantity per pack | 1 pc(s) |
|---|
Packaging content
| Manual | Yes |
|---|
Logistics data
| Pallet gross width | 2.38 m |
|---|
| Pallet gross length | 114 cm |
|---|
| Pallet gross height | 128.5 cm |
|---|
| Products per master (outer) case | 1 pc(s) |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
