Viewsonic CDEG3 Series 86“ 4K OS-Free Commercial Display
Part number CDE86G3
86IN 4K (3840X2160) OS-FREE COMMERCIAL DISPLAY, 500 NITS, 1,200:1 CONTRAST, HDMI
- OPTIMIZED FOR VIDEOCONFERENCING: Clear 4K visuals and reliable performance for smooth, professional meetings
- FAST STARTUP: Boots in seconds so meetings start on time, every time
- SIMPLE CONNECTIVITY: One USB-C cable plus HDMI for quick, easy laptop connections
- SEAMLESS AV INTEGRATION: Certified for Q-SYS, compatible with Crestron, Extron, and AMX
- FLEXIBLE INSTALLATION: Supports portrait or landscape mounting to fit any space
- Manufacturer
- ViewSonic
- Part number
- CDE86G3
- Condition
- New
- Category
- Displays › Large Format Displays
- 1GPA category
- Hardware
Overview
The ViewSonic® CDE86G3 is a 86” commercial display designed to make meetings, trainings, and videoconferences fast, simple, and professional. Its 4K UHD resolution ensures crisp visuals for presentations and video calls, while 24/7 commercial-grade reliability keeps it running smoothly in huddle rooms, conference rooms, and executive offices. Booting in as fast as 8 seconds, the CDE86G3 gets your meetings started on time without delays. A single USB-C cable plus HDMI lets you easily connect laptops, share content, and power devices, making setup quick and effortless. Q-SYS certified and compatible with Crestron, Extron, and AMX, it integrates seamlessly into existing AV systems. With no operating system to manage, this OS-free display reduces security risks and IT complexity, giving your team a safer, low-maintenance solution. The versatile 86" size fits perfectly in a variety of meeting spaces while delivering big-screen impact.
Specifications
| Panel type | VA |
|---|---|
| LED backlight | Yes |
| LED backlighting type | Direct-LED |
| Display diagonal | 2.18 m (86") |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Display diagonal (metric) | 218 cm |
| Panel life | 50000 h |
| Supported video modes | 480i, 480p, 720p, 1080i, 1080p, 2160p |
| Colour depth | 8 bit |
| Native refresh rate | 60 Hz |
| Haze rate | 25% |
| Surface hardness | 3H |
| HDMI ports quantity | 3 |
|---|---|
| HDMI version | 2.1 |
| HDMI input ports quantity | 3 |
| Consumer Electronics Control (CEC) | Yes |
| DVI port | No |
| VGA (D-Sub) input ports | 1 |
| DisplayPort version | 1.2 |
| USB port | Yes |
| USB ports quantity | 3 |
| USB version | 2.0 |
| USB connector type | USB Type-A, USB Type-C |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| PC Audio in | Yes |
| RS-232 interface | Yes |
| PC Audio out | Yes |
| Audio Return Channel (ARC) | Yes |
| Built-in speaker(s) | Yes |
|---|---|
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Product design | Digital signage flat panel |
|---|---|
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Bezel width (bottom) | 1.59 cm |
| Bezel width (side) | 1.59 cm |
| Bezel width (top) | 1.59 cm |
| Anti-glare screen | Yes |
| Purpose | Commercial |
|---|---|
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| HDCP version | 2.2 |
| Power consumption (typical) | 119.6 W |
|---|---|
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 179.2 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Built-in processor | Yes |
|---|---|
| Processor manufacturer | MediaTek |
| Processor model | MTK3683 |
| Display width | 1933.8 mm |
|---|---|
| Display depth | 79.7 mm |
| Display height | 1103.8 mm |
| Display weight | 39.5 kg |
| Package width | 2095 mm |
|---|---|
| Package depth | 185 mm |
| Package height | 1220 mm |
| Package weight | 53.8 kg |
| Remote control included | Yes |
|---|---|
| Batteries included | Yes |
| Cables included | AC, HDMI |
| Mounting kit | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Operating altitude | 0 - 3000 m |
| Ethernet LAN | Yes |
|---|
| Sustainability certificates | ENERGY STAR, Mexico Energy |
|---|---|
| Warranty period | 3 year(s) |
| Compliance certificates | Federal Communications Commission (FCC), cTUVus, RoHS |
| Headphone connectivity | 3.5 mm |
|---|---|
| Screws included | Yes |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
