Vertiv Avocent MultiViewer SVMV280DPH KVM switch Black
Part number SVMV280DPH-400
AVOCENT SV 8-PORT MULTIVIEWER KVM
Simultaneously view multiple computers on a single monitor.
Ability to interact with various computers on a single screen.
With CNS, keyboard and mouse transitions occur seamlessly when moving the cursor across window borders.
Direct interaction with any application through touch screen capabilities.
Smart-card (CAC) or biometric readers for authentication across multiple secure computers.
Manufacturer
Vertiv
Part number
SVMV280DPH-400
Condition
New
Category
Network Devices › Wireless Networking
1GPA category
Hardware
Overview
The Vertiv™ Avocent® Commercial MultiViewer KVM continues to provide the KVM solution required in accessing both classified and non-classified data. Through the use of an all new video port, the Avocent® Commercial MultiViewer KVM accepts either a standard HDMI or DP connector cable when the input/target video port has a universal connector. The Avocent® Commercial Multiviewer KVM can be used in either a single or dual display projection scenario with up to 8 computers on a single screen and features such as tiling, windowing, and touch screen.
Specifications
Ports & interfaces
Number of computers controlled
8
Keyboard port type
USB
Mouse port type
USB
Video port type
HDMI/DisplayPort
Console ports
3.5mm headphone, 3.5mm mic, HDMI, USB A
Console USB ports quantity
5
USB connector type
USB Type-A, USB Type-B
Audio connections
Yes
Performance
HD type
4K Ultra HD
Maximum resolution
3840 x 2160 pixels
Video bandwidth
30 Hz
Design
Product colour
Black
Certification
FCC B, CE, TUV US, TUV, RCM, VCCI
Display
Built-in display
No
Power
Power source
AC
Input voltage
100 - 240 V
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
0 - 80%
Storage relative humidity (H-H)
0 - 80%
Weight & dimensions
Width
442 mm
Depth
183 mm
Height
66 mm
Weight
3.7 kg
Packaging content
Cables included
AC
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
