Eaton U444-06N-H4MUC3 interface hub USB Type-C 10000 Mbit/s Black, Grey
Part number U444-06N-H4MUC3
EATON TRIPP LITE SERIES USB-C MULTIPORT ADAPTER - 4K 60 HZ HDMI, USB 3.2 GEN 2 H
- Supports UHD resolutions up to 4K @ 60 Hz (4:4:4) for heightened video quality
- Power Delivery port provides 20V 5A (100W) output for charging connected host device
- USB 3.2 Gen 2 data ports transmit to external drives and connect peripherals at 10 Gbps
- Allows convenient access to photos, videos and other data on SD and MicroSD cards
- Carries High Dynamic Range (HDR) signals for rich contrast and expanded color accuracy
- Manufacturer
- Tripp Lite
- Part number
- U444-06N-H4MUC3
- Condition
- New
- Category
- Input & Output Devices › Usb & Firewire Conn
- 1GPA category
- Hardware
Specifications
| Host interface | USB Type-C |
|---|---|
| Hub interfaces | USB 3.2 Gen 2 (3.1 Gen 2) Type-A, USB 3.2 Gen 2 (3.1 Gen 2) Type-C, HDMI |
| Ports quantity | 7 |
| Card reader integrated | Yes |
| Card reader slot | 2 |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Data transfer rate | 10000 Mbit/s |
|---|---|
| Maximum refresh rate | 60 Hz |
| Supported graphics resolutions | 3840 x 2160 |
| Colour depth | 36 bit |
| High Dynamic Range (HDR) supported | Yes |
| 3D | Yes |
| Product colour | Black, Grey |
| Housing material | Polycarbonate (PC), Acrylonitrile butadiene styrene (ABS) |
| HDCP | Yes |
| HDCP version | 2.3 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 100 W |
| Mirror mode | Yes |
| Number of displays supported | 1 |
| AWG wire size | 34/24 |
| Cable jacket material | Thermoplastic elastomer (TPE) |
| Cable length | 0.17 m |
| Connector contacts plating | Nickel |
| Certification | EN 55032 EN 55035 |
| Width | 119.9 mm |
|---|---|
| Depth | 15.5 mm |
| Height | 50 mm |
| Weight | 40 g |
| Quantity per pack | 1 pc(s) |
|---|
| Operating temperature (T-T) | 0 - 45 °C |
|---|---|
| Operating temperature (T-T) | 32 - 113 °F |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Compliance certificates | UKCA, REACH, RoHS, CE, Federal Communications Commission (FCC) |
|---|---|
| Connector 1 form factor | Straight |
| Maximum resolution | 3840 x 2160 pixels |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
