TP-Link VIGI InSight S445ZI Turret IP security camera Outdoor 2688 x 1520 pixels Ceiling
Part number INSIGHT S445ZI
4MP OUTDOOR IR MOTORIZED CAMERA 4MP OUTDOOR IR MOTORIZED CAMERA
- 5X Optical Zoom for Easy Installation and Monitoring
- 4MP Super-High Definition and IR Range Up to 60m (197ft)
- Human & Vehicle Classification
- Smart Detection
- Smart Video Enhancement Technology
- Audio and Alarm Interface Available
- IP67 Weatherproof and IK10 Vandal Proof
- H.265+ Compression Technology
- Manufacturer
- Tp Link
- Part number
- INSIGHT S445ZI
- Condition
- New
- Category
- Physical Security › Video Surveillance
- 1GPA category
- Hardware
Overview
Motorized Varifocal
By adjusting the field of view (FOV), this feature assists you in concentrating on areas of interest, minimizing invalid detection zones, and enhancing target clarity.
Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
Specifications
| Type | IP security camera |
|---|---|
| Placement supported | Outdoor |
| Connectivity technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Remote viewing | Yes |
| Dynamic range | 120 dB |
| Form factor | Turret |
|---|---|
| Mounting type | Ceiling |
| Product colour | White |
| Housing material | Metal |
| Protection features | Waterproof |
| International Protection (IP) code | IP67 |
| Weatherproof | Yes |
| Minimum illumination | 0 lx |
|---|---|
| Angle of rotation | 360° |
| Lens viewing angle, horizontal | 29.6–102 |
| Lens viewing angle, vertical | 16.8–53.8 |
| Lens viewing angle, diagonal | 34.1–122.8 |
| Tilt angle range | 0 - 77° |
| Pan range | 0 - 360° |
| Camera shutter speed | 1/3 to 1/10000 |
| Number of Privacy masking areas | 4 |
| Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
|---|---|
| Progressive scan | Yes |
| Sensor type | CMOS |
| Zoom capability | Yes |
|---|---|
| Optical zoom | 5x |
| Number of lenses | 1 |
| Focal length range | 2.7 - 13.5 mm |
| Auto focus | Yes |
| Focus | Motorized |
| Maximum aperture number | 1.6 |
| Detect distance (wide) | 66 m |
| Detect distance (tele) | 207 m |
| Observe distance (wide) | 28 m |
| Observe distance (tele) | 86 m |
| Recognize distance (wide) | 13 m |
| Recognize distance (tele) | 41 m |
| Identify distance (wide) | 7 m |
| Identify distance (tele) | 21 m |
| Night vision | Yes |
|---|---|
| Night vision distance | 60 m |
| LED type | IR |
| Number of illumination LEDs | 4 |
| Infra-red wavelength | 850 nm |
| Maximum resolution | 2688 x 1520 pixels |
|---|---|
| Total megapixels | 4 MP |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520 |
| Video recording | Yes |
| Video streaming | Yes |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Image quality adjustment | Brightness, Contrast, Mirror, Saturation, Sharpness |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 512 Kbps to 1024 Kbps |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Region of Interest (ROI) encoding | Yes |
| Smart IR | Yes |
| Audio system | 2-way |
|---|---|
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Audio formats supported | G.711 A-law |
| Sample rate | 8 kHz |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Built-in microphone | Yes |
| Number of microphones | 1 |
| Bit rate range | 0 - 64 Kbit/s |
| Ethernet LAN | Yes |
|---|---|
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
| Wi-Fi | No |
| Bluetooth | No |
| Live view | Yes |
| Number of simultaneous live view channels | 6 channels |
| Card reader integrated | Yes |
|---|---|
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
| Ethernet LAN (RJ-45) ports | 1 |
|---|---|
| DC-in jack | Yes |
| Alarm input channels | 1 |
|---|---|
| Alarm output channels | 1 |
| Built-in siren | Yes |
| Password protection | Yes |
| Video motion detection | Yes |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Alert notification type | Push notification |
| Privacy protection | Yes |
| Motion sensor | Yes |
| Mirror | Yes |
| Human and vehicle targets classification | Yes |
| Digest authentication | Yes |
| Web browser | Yes |
|---|---|
| Cloud-managed | Yes |
| Reset button | Yes |
| Power source type | DC, PoE |
|---|---|
| Power consumption (max) | 10.8 W |
| Power consumption (Power over Ethernet (PoE)) | 12 W |
| DC output voltage | 12 |
| Operating temperature (T-T) | -30 - 60 °C |
|---|---|
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Height | 92.5 mm |
|---|---|
| Diameter | 11.2 cm |
| Weight | 710 g |
| Package weight | 960 g |
|---|---|
| Package type | Box |
| Number of cameras | 1 |
|---|---|
| Mounting kit | Yes |
| Screws included | Yes |
| Drilling template included | Yes |
| Manual | Yes |
