Tp Link

TP-Link Omada EAP727 wireless access point 5012 Mbit/s White Power over Ethernet (PoE)

Part number EAP727

BE5000 WIFI 7 CEILING AP

5-Stream Wi-Fi 7: 4,324 Mbps on 5 GHz and 688 Mbps on 2.4 GHz.
1× 2.5G PoE+ Port: Ensures high-speed connectivity throughout the network.
Low Latency and Interference: 160 MHz bandwidth, Multi-Link Operation, Multi-Rus, and 4K-QAM ensure high performance for your connectivity.
Flexible Deployment and Easy Setup: Supports 802.3at PoE or DC power supply for flexible installation with Omada SDN for one-click setup.
Advanced Features: Supports centralized cloud management, PPSK, multiple portals, mesh, and seamless roaming.
More Connections and Wider Coverage: Supports 510+ concurrent connections** and covers up to 2,000 ft² (185 m²)* for reliable and extensive wireless connectivity.

Manufacturer: Tp Link
Part number: EAP727
Condition: New
Category: Network Devices › Wireless Networking
1GPA category: Hardware

Overview

Optimized Wired Performance with 2.5G PoE+ Port

With a 2.5 Gigabit Ethernet Port, EAP727 delivers remarkable multi-gigabit performance for higher bandwidth and faster Wi-Fi. Compatibility with 802.3at PoE is ideal for flexible deployment.

Specifications

Features
2.4 GHz	Yes
5 GHz	Yes
6 GHz	No
Maximum data transfer rate	5012 Mbit/s
Maximum data transfer rate (2.4 GHz)	688 Mbit/s
Maximum data transfer rate (5 GHz)	4324 Mbit/s
Ethernet LAN data rates	10,100,1000,25000 Mbit/s
Number of simultaneously connected devices (max)	510
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11ax
Cabling technology	10/100/1000/2500Base-T
Coverage area	185 m²
Number of users	510 user(s)
Bluetooth	Yes
Channel bandwidth	160 MHz
Bluetooth version	5.2
Bluetooth Low Energy (BLE)	Yes
Full duplex	Yes
Duplex mode auto-negotiation	Yes
Auto MDI/MDI-X	Yes
MIMO	Yes
MIMO type	Multi User MIMO
Spatial streams	5
Wi-Fi Multimedia (WMM)/(WME)	Yes
Wi-Fi roaming	Yes
Fast roaming	Yes
Number of WLAN connections (max)	16
VLAN support	Yes
Rate limiting	Yes
Wireless isolation	Yes
Wireless meshing	Yes

Security
Security algorithms	WPA, WPA3, WPA2
MAC address filtering	Yes
Service Set Identifier (SSID) features	Multiple SSIDs
Number of SSID supported	16
Guest access	Yes
Schedule access	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Access Control List (ACL)	Yes

Protocols
DHCP client	Yes
Supported network protocols	IPv4, IPv6, LLDP, mDNS
Management protocols	NMP v1, SNMP v2c, SNMP v3, SSH

Management features
Web-based management	Yes
Command-line interface (CLI)	Yes
Traffic statistics	Yes
Cloud-managed	Yes
Backup function	Yes
Firmware upgradeable	Yes

Ports & interfaces
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes

Power
Power over Ethernet (PoE)	Yes
DC voltage range	12 V
Input current	1.5 A
Power consumption (max)	15.6 W
Power supply	18 W

Design
Placement	Ceiling, Wall
Product colour	White
Reset button	Yes
LED indicators	Yes

Antenna
Antenna type	Internal
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Antennas quantity	5
Antenna gain level (max)	6 dBi

Performance
Built-in processor	Yes

Technical details
Wall mountable	Yes
Ethernet LAN	Yes

Certificates
Compliance certificates	CE, JRF, ICES

Weight & dimensions
Width	160 mm
Depth	160 mm
Height	36.7 mm
Weight	470 g

Packaging content
Quantity per pack	1 pc(s)

Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
Operating altitude	0 - 2000 m
Non-operating altitude	0 - 2000 m

Logistics data
Country of origin	China
