Tp Link
TP-Link Omada BE3600 Ceiling Mount Wi-Fi 7 Access Point
Part number EAP723
OMADA BE5000 CEILING WI-FI 7 AP OMADA BE5000 CEILING WI-FI 7 AP
- BE5000 Dual-Band Wi-Fi 7 (2882 Mbps on 5 GHz + 688 Mbps on 2.4 GHz)
- 1× 2.5G port unlocks the full potential of Wi-Fi 7
- 240 MHz bandwidth enables many more simultaneous transmissions
- Multi-RUs ensure the high performance of your network
- Advanced Functions: Centralized management, Mesh, and Seamless Roaming
- Manufacturer
- Tp Link
- Part number
- EAP723
- Condition
- New
- Category
- Network Devices › Wireless Networking
- 1GPA category
- Hardware
Overview
BE5000 Compact Business WiFi 7 Access Point
Optimized Wired Performance with 2.5G PoE+ Port
With a 2.5 GbE Port, EAP723 delivers remarkable multi-gigabit performance for higher bandwidth and faster WiFi. Compatibility with 802.3at PoE is ideal for flexible deployment.
Boosted Network Security
- Secure Guest Network with up to 16 SSIDs
- Boost Your Business with SMS Login
- WPA3 for Worry-Free Open Public Networks
- Rogue AP Detection
Specifications
| 2.4 GHz | Yes |
|---|---|
| 5 GHz | Yes |
| 6 GHz | No |
| Maximum data transfer rate | 3600 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 688 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2882 Mbit/s |
| Frequency band | 2.4 - 5 GHz |
| Bandwidth | 2.4 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
| Automatic channel selection | Yes |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Spread spectrum method | OFDMA |
| Fit AP mode features | Mesh networking |
| VLAN support | Yes |
| Rate limiting | Yes |
| Band steering | Yes |
| Airtime Fairness (ATF) | Yes |
| Quality of Service (QoS) support | Yes |
| BeamForming | Yes |
| Security algorithms | SNMP, SNMPv2, SNMPv3, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal |
|---|---|
| MAC address filtering | Yes |
| Access Control List (ACL) | Yes |
| Web-based management | Yes |
|---|---|
| Syslog | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
|---|---|
| DC-in jack | Yes |
| Power over Ethernet (PoE) | Yes |
|---|---|
| DC voltage range | 12 V |
| Input current | 1.5 A |
| Power consumption (max) | 18.6 W |
| Placement | Ceiling, Wall |
|---|---|
| Product colour | White |
| Reset button | Yes |
| LED indicators | Yes |
| Antenna type | Internal |
|---|---|
| Antenna gain level (max) | 5 dBi |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), RoHS |
|---|
| Width | 160 mm |
|---|---|
| Depth | 160 mm |
| Height | 36.7 mm |
| Package type | Box |
|---|
| Quantity per pack | 1 pc(s) |
|---|---|
| Mounting kit | Yes |
| Quick start guide | Yes |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
