StarTech.com 4 Port USB 2.0 Extender Hub over Cat5e/Cat6 Ethernet Cable (RJ45) - 330ft/100m Industrial Metal USB Extender Adapter Kit w/ ESD Protection - Externally Powered - 480 Mbps
Part number USB2004EXT2NA
4 PORT USB 2.0 EXTENDER HUB USB-A OVER CAT5/6 ETHERNET RJ45
- USB 2.0 EXTENDER: Connect 4 USB devices up to 330ft/100m over CAT5e/CAT6 RJ45 ethernet network cable w/ data transfer rates up to 480Mbps; LEDs monitor power, activity status, link & host connectivity_x000D_
- CONNECT REMOTE USB DEVICES: The USB extender creates a 4 port hub to remotely access USB devices like printers, cameras, plotters, keyboard/mouse, displays, & CCTV systems at a convenient location_x000D_
- INDUSTRIAL USB EXTENDER: Built w/ durable extruded aluminum construction for high wear & tear environments w/ mounting brackets incl; provides 8kV/16kV Contact/Air Electrostatic Discharge protection_x000D_
- POWERED USB EXTENDER KIT: With the included power adapter, the receiver hub at remote end provides 5V, 500mA of power per port, while the local transmitter is powered by the PC USB port_x000D_
- PLUG-AND-PLAY: The extender features driverless installation & is compatible w/ major operating systems incl. Windows, macOS, Linux; Backwards Compatible with USB 1.0 and USB 1.1 devices_x000D_
- _x000D_
- Manufacturer
- StarTech.com
- Part number
- USB2004EXT2NA
- Condition
- New
- Category
- Input & Output Devices › Usb & Firewire Conn
- 1GPA category
- Hardware
Overview
USB Extender Over CAT5e/CAT6/CAT7 | Rugged Enclosure | ESD Protection | 2-Year Warranty
The USB2004EXTNA USB 2.0 extender over ethernet lets you extend a USB 2.0 connection over distances of up to 100-meters (330-feet), over standard Cat5e or Cat6 ethernet LAN cabling.
Hi-Speed USB performance
With data bandwidth of up to 480 Mbps and no software installation required, the USB extender over Cat5e, Cat6, or Cat7 offers a fast, easy, and versatile solution for business or industrial applications with durable metal housing, an included surface-mounting bracket kit and simple plug-and-play installation.
Plus, the 100m USB extender provides up to the full 500 mA of power (with the use of an external power adapter at the remote end) allowing for greater compatibility with bus-powered USB devices.
Compatible with older USB devices
Connecting older peripherals isn’t a problem. This versatile USB over network extender is backward compatible with legacy USB 1.0 devices. The USB over ethernet hub enables almost any kind of USB device to be placed at remote locations away from the host computer.
The Choice of IT Pros Since 1985
StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to provide support for our customers both pre and post-sales
The USB2004EXT2NA is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- USB 2.0 EXTENDER: Connect 4 USB devices up to 330ft/100m over CAT5e/CAT6 RJ45 ethernet network cable w/ data transfer rates up to 480Mbps; LEDs monitor power, activity status, link & host connectivity
- CONNECT REMOTE USB DEVICES: The USB extender creates a 4 port hub to remotely access USB devices like printers, cameras, plotters, keyboard/mouse, displays, & CCTV systems at a convenient location
- INDUSTRIAL USB EXTENDER: Built w/ durable extruded aluminum construction for high wear & tear environments w/ mounting brackets incl; provides 8kV/16kV Contact/Air Electrostatic Discharge protection
Specifications
| Type | Console transmitter & receiver |
|---|---|
| Data transfer rate | 480 Mbit/s |
| Maximum transfer distance | 100 m |
| LED indicators | Activity, Link, Power |
| Cable types supported | Cat5e, Cat6, Cat7 |
| Compliance certificates | RoHS |
| Plug and Play | Yes |
| Certification | CE, FCC, REACH |
| USB 2.0 Type-A ports quantity | 4 |
|---|---|
| USB 2.0 Type-B ports quantity | 1 |
| RJ-45 ports quantity | 2 |
| Width | 76 mm |
|---|---|
| Depth | 26 mm |
| Height | 100 mm |
| Weight | 190 g |
| Package width | 195 mm |
| Package depth | 245 mm |
| Package height | 76 mm |
| Package weight | 934 g |
| Operating temperature (T-T) | 0 - 50 °C |
|---|---|
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Cables included | AC, USB |
|---|---|
| Mounting kit | Yes |
| Quick start guide | Yes |
| AC adapter included | Yes |
| Power consumption (typical) | 15 W |
|---|---|
| Input voltage | 100 - 240 V |
| Input current | 0.58 A |
| Output voltage | 24 V |
| Output current | 1 A |
| Power plug type | Type M |
| Master (outer) case width | 420 mm |
|---|---|
| Master (outer) case length | 570 mm |
| Master (outer) case height | 260 mm |
| Products per master (outer) case | 14 pc(s) |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
