StarTech.com USB 150Mbps Mini Wireless N Network Adapter - 802.11n/g 1T1R
Part number USB150WN1X1
USB WIFI ADAPTER MINI WIRELESS N NETWORK ADAPTER DONGLE 150MBPS
- Extremely compact and lightweight design
- 1 Transmitter/1 Receiver (1x1:1) antenna configuration
- Compliant with IEEE 802.11n standard, with transfer rates up to 150Mbps
- Backward compatible with IEEE 802.11b/g standards, for up to 11/54Mbps connections respectively
- Supports security features such as WEP (64-128-bit), WPA and WPA2
- Broadcast distances up to 100m indoors and 300m outdoors
- Wi-Fi Protected Setup (WPS) push button or software configuration
- Infrastructure and Ad-Hoc network modes support
- Manufacturer
- StarTech.com
- Part number
- USB150WN1X1
- Condition
- New
- Category
- Network Devices › Wireless Networking
- 1GPA category
- Hardware
Overview
Add High Speed Wireless N Connectivity to a Desktop or Laptop Computer through USB
The USB150WN1X1 USB 802.11N Mini Wireless Network Adapter allows almost any USB-enabled desktop, laptop or netbook computer system to connect to 'n'; 'g' or 'b' wireless networks. Using a 1T1R (1 Transmitter/1 Receiver) design over the 2.4GHz frequency in an extremely compact form factor, the USB adapter is capable of reaching up to 150Mbps over an 802.11n network while taking up minimal space.
Backward compatible with 802.11b/g networks (11/54Mbps), this adapter is a versatile wireless networking solution. With support for standard and advanced security options such as WEP, WPA, as well as wireless Quality of Service (QoS) support, and quick and easy setup through WPS, this USB 2.0 adapter is backed by StarTech.com's 2-year warranty and free lifetime technical support, making for an excellent wireless upgrade or first-time setup option.
Specifications
| Connectivity technology | Wireless |
|---|---|
| Host interface | USB |
| Interface | WLAN |
| USB version | 2.0 |
| Maximum data transfer rate | 150 Mbit/s |
|---|---|
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (2.4 GHz) |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| WLAN data transfer rates supported | 11,54,150 Mbit/s |
| Security algorithms | 128-bit WEP, 64-bit WEP, TKIP, WPA, WPA-AES, WPA2 |
| Full duplex | Yes |
| Maximum operating distance | 300 m |
| Maximum indoor range | 100 m |
| Maximum outdoor range | 300 m |
| Component for | PC/Laptop |
|---|---|
| Product colour | Black |
| Internal | No |
| Chipset | Realtek - RTL8188EUS |
| Plug and Play | Yes |
| Mean time between failures (MTBF) | 44000 h |
| Certification | CE, FCC, REACH |
| Output voltage | 5 V |
|---|---|
| USB powered | Yes |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
|---|---|
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019 |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -20 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Width | 15 mm |
|---|---|
| Depth | 19 mm |
| Height | 8 mm |
| Weight | 2.2 g |
| Drivers included | Yes |
|---|---|
| Package width | 95 mm |
| Package depth | 143 mm |
| Package height | 14 mm |
| Package weight | 42 g |
| Manual | Yes |
|---|
| Compliance certificates | RoHS |
|---|
| Harmonized System (HS) code | 85176990 |
|---|---|
| Master (outer) case width | 378 mm |
| Master (outer) case length | 345 mm |
| Master (outer) case height | 246 mm |
| Products per master (outer) case | 100 pc(s) |
| Housing material | Plastic |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
