StarTech.com 4-Bay Hard Drive Duplicator and Eraser, Standalone 1:3 SATA HDD/SSD Cloner/Copier, USB 3.0 / eSATA to SATA Docking Station, Hard Drive Duplicator and Sanitizer Dock, Toolless / Top-Loading Design
Part number SATDOCK4U3RE
4BAY HARD DRIVE DUPLICATOR DOCK HDD SSD CLONER WIPER DISK ERASER
- DUPLICATE, ERASE AND DOCK: This 4-bay external cloner and drive eraser/ wiper performs standalone cloning or erasing of 2.5/3.5" SATA drives; Hard disk docking station for quick access to your 2.5/3.5" SATA drives over USB or eSATA
- DRIVE COMPATIBILITY: Works with 2.5/3.5" SATA and IDE SSDs/HDDs of any capacity; Included IDE cable adapters support 40-pin/3.5in and 44-pin/2.5in drives; OS Independent; Hardware includes eSATA and USB-A cables and Universal Power Adapter
- DUPLICATION AND ERASE MODES: Up to 4.2 GB/min Standalone sector-by-sector cloning; Target disk must be equal/larger than the source disk; Supports Quick Erase & Secure Erase (NIST SP 800-88 Rev 1 Purge); Disk mount / File transfer / Backup / Recovery tool
- LCD MENU DISPLAY: Use push button menu navigation to select duplication and erase modes, and check drive info; USB 3.2 Gen 1 (5 Gbps) or eSATA (3 Gbps) Host Device Connection (optional); Top-Loading w/ Drive Doors & Eject Buttons; Multi-function LEDs
- THE IT PRO'S CHOICE: Designed and built for IT Professionals, this hard drive copier and wiper tool is backed for 2 years, including free lifetime 24/5 multilingual technical assistance
- Manufacturer
- StarTech.com
- Part number
- SATDOCK4U3RE
- Condition
- New
- Category
- System Components › Computer Cases
- 1GPA category
- Hardware
Overview
Quad Bay Hard Drive Duplicator & Eraser 2.5/3.5" HDD/SSD Disk Cloner
The SATDOCK4U3RE USB 3.0 and eSATA 1-to-3 Hard Drive Duplicator docking station enables you to duplicate/clone a single SATA hard drive to up to three other SATA drives simultaneously, as a standalone device. The duplicator can also function as a regular 4-bay hard drive docking station, by connecting to a host computer system. Large capacity drives (tested with up to 4TB 3.5" and 1TB 2.5" drives per bay) can be used to greatly enhance your computer's storage/backup capabilities.
Able to perform 1:3 sector duplication, including HPA, from a single SATA drive onto three others simultaneously (at a rate of up to 72 MBps), the duplicator/docking station can save you time and effort. As an external HDD dock, it can be connected to your host computer through USB 3.0 or eSATA, providing data transfer speeds up to 5 Gbps or 3Gbps respectively, from the hard drives to your computer system.
Features Quick and Secure Erase functions and support for IDE hard drives using the included SATA to IDE hard drive adapter (SAT2IDEADP). This drive eraser ensures data is purged (a secure erase) which is required by government agencies and organizations who have strict guidelines on deleting data. Purging is a very secure method of erasing data from your storage device which complies with the NIST 800-88 Rev. 1 media sanitation standard established by the National Institute of Standards and Technology.
Specifications
| Product type | HDD duplicator |
|---|---|
| Product colour | Black |
| Housing material | Plastic |
| Number of simultaneous copies | 3 copies |
| Interface | USB/eSATA |
| USB connector type | USB Type-B |
| Duplicator operating modes | Copy |
| Maximum supported storage capacity | 16 TB |
| Plug and Play | Yes |
| Display | LCD |
| Chipset | JMicron - JMB394 + JMS539 |
| Number of fans | 2 fan(s) |
| Fan diameter | 6 cm |
| Port multiplier | Yes |
| LED indicators | Activity, Power |
| Certification | CE |
| Supported HDD sizes | 2.5,3.5" |
|---|---|
| Supported HDD interfaces | Serial ATA, Serial ATA II |
| Compatible operating systems | Windows 2000/ XP(32/64-bit)/ Server 2003(32/64-bit)/ Vista(32/64-bit)/ 7(32/64-bit)/ Server 2008 R2, Mac OS X, Linux |
|---|
| Power consumption (typical) | 78 W |
|---|---|
| AC input voltage | 110-240 V |
| Output voltage | 12 V |
| Output current | 6.5 A |
| Included power plug types | EU, NA, UK |
| Dimensions (WxDxH) | 285 x 170 x 94 mm |
|---|---|
| Weight | 1.1 kg |
| Package width | 223 mm |
|---|---|
| Package depth | 344 mm |
| Package height | 181 mm |
| Package weight | 2.73 kg |
| Cables included | SATA, USB, eSATA |
|---|---|
| AC adapter included | Yes |
| Manual | Yes |
| Operating relative humidity (H-H) | 8 - 90% |
|---|---|
| Operating temperature (T-T) | 5 - 80 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Compliance certificates | RoHS |
|---|
| Master (outer) case length | 375 mm |
|---|---|
| Master (outer) case width | 377 mm |
| Master (outer) case height | 481 mm |
| Products per master (outer) case | 4 pc(s) |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
