StarTech.com MSA Uncoded Compatible 2m 40G QSFP+ to QSFP+ Direct Attach Breakout Cable Twinax - 40 GbE QSFP+ Copper DAC 40 Gbps Low Power Passive Transceiver Module DAC - TAA
Part number QSFPMM2M
6FT QSFP+ DIRECT ATTACH CABLE SFP MODULE MSA 40G SFP TRANSCEIVER
- MSA UNCODED QSFP+ CABLE (DAC): 40G direct attach cable works with MSA compliant switches the accept uncoded transceivers and modules
- StarTech.com SFP cables are backed by a lifetime warranty
- TECHNICAL SPECS: 2m (6.5ft) / 40 Gbps / Passive Twinax (Copper) / 2x QSFP+ Pluggable Connector / 100 Ohm Impedance / 30 AWG Wire Gauge / PVC Cable Jacket / Hot swappable / MSA Compliant
- DESIGNED FOR SERVER ROOMS: DAC is a cost-effective copper alternative to fiber cable inside & between racks. Factory termination means high performance & reliability with less maintenance.
- OUTSTANDING SUPPORT: Backed by StarTech.com for the life of the cable itself, not your equipment; our cables won't void your OEM support and with access to our Tech Advisors 5/24
- WORKS WITH MSA COMPLIANT SWITCHES: Low power 40 GbE DAC also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules and transceivers
- Manufacturer
- StarTech.com
- Part number
- QSFPMM2M
- Condition
- New
- Category
- Computer Systems › Server Computers
- 1GPA category
- Hardware
Overview
Copper QSFP+ Cable | 40 Gbps | Passive DAC | Lifetime Warranty
The QSFPMM2M is an MSA compliant direct-attach copper QSFP+ cable that’s designed, programmed and tested to work in 40G network deployments. It delivers dependable 40 GbE connectivity over copper cabling, which is a cost-effective alternative to fiber-optic cable setups.
This passive Twinax cable supports 40 Gigabit Ethernet applications connected through QSFP+ (Mini-GBIC) ports. The cable is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
At 2 meters long and designed for high-speed performance, this copper QSFP+ cable is ideal for medium-distance applications such as across-rack network switch or server connections.
StarTech.com SFP Cables
All StarTech.com SFP & SFP+ cables are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of direct-attach SFP Cables and SFP modules, providing the convenience and reliability you need to ensure dependable network performance.
Specifications
| Cable length | 2 m |
|---|---|
| InfiniBand protocol | Yes |
| Connector 1 | QSFP+ |
| Connector 2 | QSFP+ |
| Connector gender | Male/Male |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Product colour | Black |
| Data transfer rate | 40 Gbit/s |
| Data transfer rate | 40000 Mbit/s |
| Cable shielding | U/FTP (STP) |
| Jacket material | Polyvinyl chloride (PVC) |
| Compliance certificates | CE, RoHS |
|---|
| Weight | 175 g |
|---|
| Package width | 251 mm |
|---|---|
| Package depth | 265 mm |
| Package height | 28 mm |
| Package weight | 190 g |
| Quantity per pack | 1 pc(s) |
|---|
| Master (outer) case width | 312 mm |
|---|---|
| Harmonized System (HS) code | 84733080 |
| Master (outer) case length | 406 mm |
| Master (outer) case height | 308 mm |
| Products per master (outer) case | 50 pc(s) |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
