StarTech.com

StarTech.com 24in Internal USB Motherboard Header to 2 Port Serial RS232 Adapter - TAA

Part number ICUSB232INT2

24IN MOTHERBOARD SERIAL PORT USB TO 2 PORT SERIAL RS232 ADAPTER

Single chip USB to asynchronous serial data transfer interface
Supports COM port retention
Bus Powered – no separate power supply or battery required
FIFO receive and transmit buffers for high data throughput.
Synchronous and asynchronous bit bang interface options with RD# and WR# strobes
UHCI/OHCI/EHCI host controller compatible
USB 2.0 Full Speed compatible

Manufacturer: StarTech.com
Part number: ICUSB232INT2
Condition: New
Category: Input & Output Devices › Serial/Parallel & Io
1GPA category: Hardware

Overview

Add two RS232 serial ports to any system with an available USB motherboard header

The ICUSB232INT2 USB to Serial Adapter lets you add 2 RS232 ports to any desktop system that is equipped with an available USB motherboard header. Unlike standard USB to serial cables, this cable is designed for use inside the PC case, affording an entirely internal solution with no mess or extra adapters needed. This compact and simple USB adapter offers a cost-effective solution that bridges the compatibility gap between modern computers and legacy serial peripherals. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Specifications

Ports & interfaces
Host interface	IDC
Output interface	Serial
Serial ports quantity	2
Serial interface type	RS-232

Design
Internal	Yes
Certification	Microsoft WHQL, CE, FCC

Features
Baud rate	115.2 Kbit/s
FIFO (First In, First Out)	256 B
Data bits	7, 8
Stop bits	1, 2
Plug and Play	Yes

Operational conditions
Operating temperature (T-T)	-10 - 80 °C
Storage temperature (T-T)	-20 - 100 °C
Operating relative humidity (H-H)	5 - 85%

System requirements
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 2000, Windows 2000 Professional, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows CE, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura
Linux operating systems supported	Yes
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016

Technical details
Compliance certificates	RoHS

Weight & dimensions
Width	120 mm
Depth	68 mm
Height	19 mm
Weight	63 g

Packaging data
Mounting brackets included	Yes
Drivers included	Yes
Manual	Yes
Package width	142 mm
Package depth	174 mm
Package height	33 mm
Package weight	153 g

Logistics data
Harmonized System (HS) code	84733020
Products per master (outer) case	75 pc(s)
Master (outer) case width	350 mm
Master (outer) case length	693 mm
Master (outer) case height	314 mm

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
