Shuttle Nano PC NA10H7, AMD Ryzen™ 7-8845HS APU, Radeon780M , 2xHDMI, 2xUSB-C 4.0(DP), 2x2.5Gbit LAN, 24/7 permanent operation, incl. VESA
Part number NA10H7
SHUTTLE NANO NA10H7 BAREBONE PC AMD RYZEN 7 8845HS NO RAM/SSD/OS
- 1L sized PC Black
- Built-in processor AMD 8845HS 3.8 GHz
- 2 SO-DIMM Maximum internal memory: 64 GB DDR5-SDRAM
- SSD M.2
- On-board graphics card AMD Radeon 780M
- Ethernet LAN
- Manufacturer
- SHUTTLE COMPUTER
- Part number
- NA10H7
- Condition
- New
- Category
- Computer Systems › Barebones Systems
- 1GPA category
- Hardware
Overview
Affordable AI-PC in Nano Format Powered by AMD Ryzen™ Zen 4 APU
The Shuttle XPC Barebone NA10H7, part of the XPC nano family, is powered by the AMD Ryzen™ 7-8845HS APU, featuring the cutting-edge Zen 4 microarchitecture. With 8 cores, 16 threads, and AMD Radeon™ 780M graphics, it delivers exceptional performance and is primed for AI-readiness.
The integrated Neural Processing Unit (NPU) achieves 16 TOPS of AI performance, while the combined NPU, CPU, and GPU offer a total of 39 TOPS, enabling demanding AI workloads. Supporting up to 64 GB of DDR5 memory, the NA10H7 also boasts a comprehensive array of I/O options, including four UHD graphics ports and two USB4 ports.
Designed as a cost-effective, high-performance solution for generative AI tasks, the NA10H7 excels in a variety of applications, such as content creation, gaming, entertainment, office work, commerce, and AIoT implementations. With its compact nano chassis and advanced connectivity features, it sets a new standard for affordable AI-PCs.
Specifications
| Processor manufacturer | AMD |
|---|---|
| Processor family | AMD Ryzen™ 7 |
| Processor generation | AMD Ryzen 8000 Series |
| Processor model | 8845HS |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor boost frequency | 5.1 GHz |
| Processor frequency | 3.8 GHz |
| Built-in processor | Yes |
| L2 cache | 8 MB |
| L3 cache | 16 MB |
| Thermal Design Power (TDP) | 45 W |
| Internal memory installed | No |
|---|---|
| Memory slots type | SO-DIMM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 5600 MHz |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Memory voltage | 1.1 V |
| Non-ECC | Yes |
| Storage drives installed | No |
|---|---|
| Supported storage drive types | SSD |
| Storage drive sizes supported | M.2 |
| SSD form factor | M.2 |
| Storage drive interface | PCI Express |
| NVMe | Yes |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
| On-board graphics card | Yes |
|---|---|
| Graphics card family | AMD |
| On-board graphics card model | AMD Radeon 780M |
| Number of displays supported | 4 |
| BIOS type | UEFI AMI |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio chip | Realtek ALC269 |
| Built-in speaker(s) | No |
|---|
| Ethernet LAN | Yes |
|---|---|
| Wi-Fi | No |
| LAN controller | Realtek RTL8125B |
| USB 2.0 ports quantity | 1 |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 5 |
| USB4 Gen 2x2 ports quantity | 2 |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Chassis type | 1L sized PC |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| LED indicators | Power |
| Housing material | Plastic |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Product type | Mini PC barebone |
| Compliance certificates | BSMI, CB, CE, Federal Communications Commission (FCC), RoHS, cTUVus |
|---|
| Harmonized System (HS) code | 84714900 |
|---|
| Windows operating systems supported | Windows 11 x64 |
|---|---|
| Linux operating systems supported | Yes |
| Sustainability certificates | ENERGY STAR, ErP |
|---|
| Power supply type | External AC adapter |
|---|---|
| Power supply | 120 W |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| AC adapter output voltage | 19 V |
| AC adapter output current | 6.32 A |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Width | 132 mm |
|---|---|
| Depth | 143 mm |
| Height | 55 mm |
| Weight | 800 g |
| Package weight | 1.7 kg |
| Power cord included | Yes |
|---|---|
| AC adapter included | Yes |
| Quick start guide | Yes |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
