Sharp A824U Standard throw projector 7500 ANSI lumens 3LCD WUXGA (1920x1200) White
Part number XP-A824U-W
8,200 LUMEN, WUXGA, LASER, LCD PROJECTOR, WHITE
- No lamp replacement – up to 20,000 h maintenance free operation possible due to Laser Light Source.
- No filter service required – a completely sealed optical laser LCD engine allows a filter-free design. Brilliant colour brightness is maintained and servicing costs need no longer feature in your budget.
- Super Silent operation – patented sealed light engine incorporating innovative fan design not only protects against dust ingress but dramatically reduces noise.
- Impress with vivid colour & contrast – brilliant white and wide colour space with high dynamic contrast supporting HDR10 standard via HDMI interface.
- Incredible visualisation capabilities – impressive free tilt and portrait installation capability, unique geometric adjustment, tiling and camera based blending.
- Manufacturer
- Sharp
- Part number
- XP-A824U-W
- Condition
- New
- Category
- Presentation Devices › Projectors
Overview
Precision, Clarity, Enduring Performance
Delivering consistent, reliable performance with vivid colour and clarity, the Sharp A Series is engineered for fixed installations that require dependable image quality and low maintenance.
With precise white point calibration and an extended colour space, the A Series uses 12-bit colour signal processing to achieve rich saturation and deep contrast, perfect for detailed visual content in education, public displays, and simulation environments. Its super-silent operation makes it well suited to acoustically sensitive spaces such as lecture halls, museums, and contol rooms.
The sealed optical engine, rated IP5X against dust ingress, maintains stable image quality and sustained brightness over time. The filter-less LCD design combined with a laser light source removes the need for lamp replacements, minimising service costs and enabling up to 20,000 hours of operation.
Installation is streamlined with Sharp's ProAssist software, enabling remote setup and adjustment even when the projector is inaccessible. Wide lens shift, along with advanced features such as HDBaseT-out, blending, and stacking capabilities, ensures flexible integration in complex environments.
Specifications
| Supported aspect ratios | 16:10 |
|---|---|
| Screen size compatibility | 1016 - 12700 mm (40 - 500") |
| Projection distance | 0.7 - 50.9 m |
| Projector brightness | 7500 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Horizontal scan range | 15 - 153 kHz |
| Vertical scan range | 24 - 120 Hz |
| Keystone correction, horizontal | -40 - 40° |
| Keystone correction, vertical | -40 - 40° |
| Light source type | Laser |
|---|---|
| Service life of light source | 20000 h |
| Focus | Motorized |
|---|---|
| Horizontal lens shift range | -20 - 20% |
| Vertical lens shift range | -50 - 10% |
| USB 2.0 Type-A ports quantity | 1 |
|---|---|
| Audio (L/R) in | 1 |
| Audio (L/R) out | 2 |
| Serial interface type | RS-232 |
| HDMI ports quantity | 2 |
| 3G-SDI input | 1 |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Noise level (economic mode) | 28 dB |
|---|---|
| HDCP | Yes |
| Noise level | 34 dB |
| Product type | Standard throw projector |
|---|---|
| Product colour | White |
| Built-in display | No |
|---|
| Power source | AC |
|---|---|
| Power consumption (typical) | 615 W |
| Power consumption (standby) | 0.28 W |
| Power consumption (economy mode) | 560 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
| Width | 599 mm |
|---|---|
| Depth | 490 mm |
| Height | 208 mm |
| Weight | 24.1 kg |
| Remote control included | Yes |
|---|---|
| Remote control type | IR |
| Cables included | AC |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
