Sharp XP-A824U Standard throw projector 7500 ANSI lumens 3LCD WUXGA (1920x1200) 3D Black
Part number XP-A824U-B
8,200 LUMEN, WUXGA, LASER, LCD PROJECTOR, BLACK
- Standard throw projector Black
- 3LCD 7500 ANSI lumens
- Laser 20000 h
- WUXGA (1920x1200) 16:10 3000000:1
- Screen size compatibility: 1016 - 12700 mm (40 - 500")
- Focus: Motorized
- Ethernet LAN
- 3D
- AC 615 W
- Manufacturer
- Sharp
- Part number
- XP-A824U-B
- Condition
- New
- Category
- Presentation Devices › Projectors
Overview
Extreme efficiency in the sharpest detail
With precise white point calibration and an extended colour space, the A Series uses 12-bit colour signal processing to achieve rich saturation and deep contrast, perfect for detailed visual content in education, public displays, and simulation environments.
The sealed optical engine, rated IP5X against dust ingress, maintains stable image quality and sustained brightness over time. The filter-less LCD design combined with a laser light source removes the need for lamp replacements, minimising service costs and enabling up to 20,000 hours of operation.
Installation is streamlined with Sharp’s ProAssist software, enabling remote setup and adjustment even when the projector is inaccessible. Wide lens shift, along with advanced features such as HDBaseT-out, blending, and stacking capabilities, ensures flexible integration in complex environments.
Specifications
| Supported aspect ratios | 16:10 |
|---|---|
| Screen size compatibility | 1016 - 12700 mm (40 - 500") |
| Projection distance | 0.7 - 50.9 m |
| Projector brightness | 7500 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Horizontal scan range | 15 - 153 kHz |
| Vertical scan range | 24 - 120 Hz |
| Keystone correction, horizontal | -40 - 40° |
| Keystone correction, vertical | -40 - 40° |
| Light source type | Laser |
|---|---|
| Service life of light source | 20000 h |
| Focus | Motorized |
|---|---|
| Horizontal lens shift range | -20 - 20% |
| Vertical lens shift range | -50 - 10% |
| 3D | Yes |
|---|
| USB 2.0 Type-A ports quantity | 1 |
|---|---|
| Audio (L/R) in | 1 |
| Audio (L/R) out | 2 |
| Serial interface type | RS-232 |
| HDMI ports quantity | 2 |
| 3G-SDI input | 1 |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Noise level (economic mode) | 28 dB |
|---|---|
| HDCP | Yes |
| Noise level | 34 dB |
| Product type | Standard throw projector |
|---|---|
| Product colour | Black |
| Built-in display | No |
|---|
| Power source | AC |
|---|---|
| Power consumption (typical) | 615 W |
| Power consumption (standby) | 0.28 W |
| Power consumption (economy mode) | 560 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
| Width | 599 mm |
|---|---|
| Depth | 490 mm |
| Height | 208 mm |
| Weight | 24.1 kg |
| Remote control included | Yes |
|---|---|
| Remote control type | IR |
| Cables included | AC |
