Products › Presentation Devices
Sharp XP-A201U-B Short throw projector 20000 ANSI lumens 3LCD WUXGA (1920x1200) Black
Part number XP-A201U-B
20000 LUMEN INSTALLATION PROJEC 4K READY LCD RB LASER PROJECTOR
- No lamp replacement – up to 25,000 h maintenance free operation possible due to Laser Light Source
- No filter service required – the enhanced sealed optical laser LCD engine allows a filter-free design, IP5X rated against dust ingress. Brilliant colour brightness is maintained and servicing costs need no longer feature in your budget
- Compact design – a large venue projector with a comparatively small footprint and light weight design
- Impress with vivid colour & contrast – brilliant white and wide colour space with high dynamic contrast supporting HDR10 standard via HDMI interface
- Incredible visualisation capabilities – impressive free tilt and portrait installation capability, unique geometric adjustment, picture in picture, tiling and camera based blending
- Manufacturer
- Sharp
- Part number
- XP-A201U-B
- Condition
- New
- Category
- Presentation Devices › Projectors
Overview
High brightness with extreme efficiency
For long-lasting imaging performance at high brightness with movie-quality colour rendition, the Sharp A201U encapsulates efficiency. Every aspect of its design forges maximum productivity, achieving remarkable performance alongside impressive cost, space and energy saving.
Born of NEC heritage, the A201U presents the same high quality Japanese design and engineering standards as its predecessor, the NEC PA Series, delivering on Sharp/NEC’s promise of quality, service and sustainability. This next generation model utilises legacy PA Series lenses securing against e-waste and reducing costs.
The first and only LCD projector featuring RB laser technology, this innovative solution is highly efficient in producing the most intensely natural tones, minimising power consumption whilst delivering brilliant, almost DCI-P3 colour performance at high brightness levels. Consistently superior imaging quality is safeguarded with an IP5X rated optical engine, sealed against even the finest dust particles and eliminating maintenance demands.
Featuring advanced installation capabilities, easily managed with full ProAssist support, the compact Sharp A201U delivers the reliability, functionality and value as demanded by higher education, corporate, leisure and museum applications.
Specifications
| Supported aspect ratios | 16:10, 16:9 |
|---|---|
| Screen size compatibility | 1524 - 12700 mm (60 - 500") |
| Projection distance | 0.68 - 80.77 m |
| Projector brightness | 20000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Horizontal scan range | 15 - 153 kHz |
| Vertical scan range | 24 - 120 Hz |
| Keystone correction, horizontal | -40 - 40° |
| Keystone correction, vertical | -30 - 30° |
| Light source type | Laser |
|---|---|
| Service life of light source | 25000 h |
| Focus | Motorized |
|---|---|
| Zoom capability | Yes |
| Zoom type | Auto |
| Horizontal lens shift range | -25 - 25% |
| Vertical lens shift range | 65 - 65% |
| Full HD | Yes |
|---|---|
| 3D | No |
| HDBaseT port | Yes |
|---|---|
| USB 2.0 Type-A ports quantity | 1 |
| Serial interface type | RS-232 |
| PC Audio out | Yes |
| HDMI ports quantity | 2 |
| 3G-SDI input | 1 |
| AC (power) in | Yes |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Noise level (economic mode) | 34 dB |
|---|---|
| Noise level | 42 dB |
| Certification | CE; EAC; ErP; RoHS; TUEV |
| Product type | Short throw projector |
|---|---|
| Product colour | Black |
| Built-in display | No |
|---|
| Power source | AC |
|---|---|
| Power consumption (typical) | 1530 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
| Width | 650 mm |
|---|---|
| Depth | 549 mm |
| Height | 262 mm |
| Weight | 38.7 kg |
| Remote control included | Yes |
|---|---|
| Remote control type | IR |
| Manual | Yes |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
