Products › Presentation Devices
Sharp A175UL-W (WHITE CABINET) IS A 16,000-LUMEN (CENTER: 17,000LM) LCD LASER PR Standard throw projector 17000 ANSI lumens 3LCD WUXGA (1920x1200)
Part number XP-A175U-W
17000 LUMEN WUXGA LASER LCD WHITE PRODUCT SHIPS WITHOUT A
- No lamp replacement – up to 20,000 h maintenance free operation possible due to Laser Light Source.
- No filter service required – the enhanced sealed optical laser LCD engine allows a filter-free design, IP5X rated against dust ingress. Brilliant colour brightness is maintained and servicing costs need no longer feature in your budget
- Compact design – a large venue projector with a comparatively small footprint and light weight design.
- Impress with vivid colour & contrast – brilliant white and wide colour space with high dynamic contrast supporting HDR10 standard via HDMI interface.
- Incredible visualisation capabilities – impressive free tilt and portrait installation capability, unique geometric adjustment, picture in picture, tiling and camera based blending.
- Manufacturer
- Sharp
- Part number
- XP-A175U-W
- Condition
- New
- Category
- Presentation Devices › Projectors
Overview
A new class of bright projection
The enhanced sealed optical engine allows a filter-free design, IP5X rated against dust ingress - no possibility of dust contaminating the LCD panels for long-term picture stability and brilliant colour brightness. What’s more, with our filterless LCD projector design and no lamp replacement, service costs are dramatically reduced for a low cost of ownership and up to 20,000 hours life-time.
Sharp customers can easily make the transition to benefit from the latest laser technology. The A175U is a professional installation projector featuring advanced installation capabilities as demanded by higher education, leisure and museum applications.
Specifications
| Supported aspect ratios | 16:10 |
|---|---|
| Screen size compatibility | 1524 - 12700 mm (60 - 500") |
| Projection distance | 0.68 - 80.77 m |
| Projector brightness | 17000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Horizontal scan range | 15 - 153 kHz |
| Vertical scan range | 24 - 120 Hz |
| Keystone correction, horizontal | -40 - 40° |
| Keystone correction, vertical | -30 - 30° |
| Light source type | Laser |
|---|---|
| Service life of light source | 20000 h |
| Focus | Motorized |
|---|---|
| Horizontal lens shift range | -25 - 25% |
| Vertical lens shift range | -65 - 65% |
| 3D | No |
|---|
| USB 2.0 Type-A ports quantity | 1 |
|---|---|
| Audio (L/R) in | 1 |
| Audio (L/R) out | 2 |
| Serial interface type | RS-232 |
| HDMI ports quantity | 2 |
| 3G-SDI input | 1 |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Noise level (economic mode) | 37 dB |
|---|---|
| HDCP | Yes |
| Noise level | 43 dB |
| Product type | Standard throw projector |
|---|---|
| Product colour | White |
| Built-in display | No |
|---|
| Power source | AC |
|---|---|
| Power consumption (typical) | 990 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (economy mode) | 890 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
| Width | 599 mm |
|---|---|
| Depth | 490 mm |
| Height | 238 mm |
| Weight | 28.7 kg |
| Remote control included | Yes |
|---|---|
| Remote control type | IR |
| Cables included | AC |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
