Sharp 55 Ultra-Narrow Bezel Professional-Grade Display LCD Indoor
Part number PN-UN553V
55 ULTRA-NARROW BEZEL PROFESSIONAL-GRADE DISPLAY
- Easy installation – effortlessly set up you wall display with Auto TileMatrix and out-of-the-box calibrations. Save time by plugging in ready-to-use image presets for predefined application scenarios.
- Enhanced imaging performance – advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.
- Lifelike and consistent colour – expect colour reproduction that feels true to life with IPS panel technology, the top choice when it comes to colour consistency. The S-IPS panel ensures that perfect visibility is maintained in landscape and portrait mode and at extreme viewing angles as viewers pass by.
- Secure Reliability and Longevity of Video Walls – unique NEC heat management system enables the user to monitor and control the heat inside the display.
- Cost Saving Device Management – save effort whilst managing all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
- Manufacturer
- Sharp
- Part number
- PN-UN553V
- Condition
- New
- Category
- Displays › Large Format Displays
Overview
Seamless video walls to amplify your brand
Advanced intelligent features and imaging performance powered by SpectraViewTM ensure precise and consistent visualisation across the entire wall, The 55-inch Sharp MultiSync® UN553V creates the impression of a single, continuous surface for clear and engaging content presentation.
Engineered for 24/7 operation in public spaces, the series combines robust metal construction with advanced thermal management to deliver reliable, long-lasting performance. Positioned to fulfil the requirements of demanding signage applications, it is suited for retail environments, digital-out-of-home media, leisure and museum venues, as well as rental and staging scenarios.
Specifications
| Display technology | LCD |
|---|---|
| Display diagonal | 139.7 cm (55") |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Panel type | IPS |
| LED backlight | Yes |
| LED backlighting type | Direct-LED |
| Native aspect ratio | 16:9 |
| Display brightness | 500 cd/m² |
| Contrast ratio (typical) | 3500:1 |
| Native refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Horizontal scan range | 26 - 134 kHz |
| Vertical scan range | 23 - 86 Hz |
| Haze rate | 25% |
| Colour gamut | 72% |
| Display diagonal (metric) | 138.8 cm |
| Placement supported | Indoor |
|---|---|
| Orientation | Horizontal/Vertical |
| Wall mountable | Yes |
| VESA mounting | Yes |
| Panel mounting interface | 400 x 400 mm |
| HDMI ports quantity | 3 |
|---|---|
| HDMI input ports quantity | 2 |
| HDMI output ports quantity | 1 |
| VGA (D-Sub) input ports | 1 |
| DisplayPorts quantity | 3 |
| DisplayPorts in | 2 |
| DisplayPorts out | 1 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| RS-232 input ports | 1 |
| HDCP | Yes |
| Audio input | Yes |
| Audio output | Yes |
| Power consumption (typical) | 140 W |
|---|---|
| Power consumption (standby) | 0.5 W |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 122 kWh |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width | 1212.7 mm |
|---|---|
| Depth | 106.4 mm |
| Height | 683.5 mm |
| Weight | 28.6 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
