Sharp PN-LA862 Interactive flat panel 2.18 m (86") LCD 500 cd/m² 4K Ultra HD Black Touchscreen 24/7
Part number PN-LA862
86IN INTERACTIVE DISPLAY 20PT TOUCH RS-232C 500 CD/M2 3840X2160
- Most natural writing experience – InGlass™ M5 premium touch system supports patented pressure sensitivity using passive pens as well as Windows Ink and palm rejection
- Secure by design – the non-Android platform with additional security features meets the highest IT security standards
- Optional Windows based Intel SDM slot-in PC – driving unlimited versatility with powerful integrated computing. Includes Sharp’s Meeting Launcher for quick and easy access to your apps offering a secure and locked environment
- Increase your productivity – benefit from a free one-year license for FlatFrog Board for Rooms. FlatFrog Board whiteboard software makes hybrid work easy and productive for everyone
- Energy efficiency – built-in functionality including an ambient light sensor, human presence detection and eco modes help to reduce power consumption
- Manufacturer
- Sharp
- Part number
- PN-LA862
- Condition
- New
- Category
- Input & Output Devices › Pointing Devices
Overview
Safeguarding security and promoting productivity in hybrid meetings
Bringing advanced professional functionality to Enterprise users, the Sharp/NEC LA series safeguards the highest IT security standards whilst supporting maximum choice and flexibility. An Intel™SDM slot expands the display’s customisable capability allowing safe and seamless integration into corporate IT systems, or benefit from pre-installed functionality including Sharp Meeting Launcher for quick access to your favourite apps and VC platforms, FlatFrog Board collaborative whiteboarding software, and AirServer™ for wireless screen sharing.
Featuring InGlass™ M5 premium touch technology, users benefit from the most natural writing experience and advanced interactive functionality. The high brightness output, high haze panel and premium glass coating delivers best readability in well-lit meeting rooms, without distraction from reflections, glare or fingerprints.
The LA series supports orientation any which way, including face up, allowing table-top, tilted desk or multi-board side-by-side installations for up to three displays. Users can connect their own notebook, safely and securely via a USB-C connection, providing best versatility in hybrid meetings and spontaneous collaborative interactions.
The LA series integrates elegantly and seamlessly into high-end meeting rooms and boardrooms providing trusted long-life performance whilst making minimal energy demands.
Specifications
| Panel type | IPS |
|---|---|
| LED backlight | Yes |
| LED backlighting type | Direct-LED |
| Display diagonal | 2.18 m (86") |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | Yes |
| Touchscreen technology | InGlass |
| Number of simultaneous touchpoints | 20 |
| Multi-touch | Yes |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Display diagonal (metric) | 217.4 cm |
| Number of displays | 1 |
| Colour saturation | 68% |
| Horizontal scan range | 15 - 135 kHz |
| Vertical scan range | 23 - 76 Hz |
| Native refresh rate | 60 Hz |
| Haze rate | 8% |
| HDMI ports quantity | 4 |
|---|---|
| HDMI input ports quantity | 2 |
| HDMI output ports quantity | 2 |
| DisplayPorts quantity | 2 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| USB port | Yes |
| USB ports quantity | 5 |
| USB version | 2.0 |
| USB connector type | USB Type-B |
| Ethernet LAN (RJ-45) ports | 1 |
| Product design | Interactive flat panel |
|---|---|
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Bezel width (bottom) | 3.23 cm |
| Bezel width (side) | 4.8 mm |
| Bezel width (top) | 4.8 mm |
| Anti-glare screen | Yes |
| Mounting type | Wall |
| Purpose | Commercial |
|---|---|
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| Power consumption (typical) | 275 W |
|---|---|
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| Display width | 1965.4 mm |
|---|---|
| Display depth | 86.5 mm |
| Display height | 1163.9 mm |
| Display weight | 71.5 kg |
| Package width | 2095 mm |
|---|---|
| Package depth | 225 mm |
| Package height | 1310 mm |
| Package weight | 87 kg |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 100 Mbit/s |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
