Sharp MA551-PT Signage Display Digital signage flat panel 139.7 cm (55") 500 cd/m² 4K Ultra HD Black Touchscreen 24/7
Part number MA551-PT
MULTISYNC MA551-PT 55 LED LCD MULTISYNC MA551-PT 55 LED LCD
- Unhindered readability – no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation
- Wide colour gamut – high-performance panel technology delivers a wider spectrum of colours for a superb visual experience
- Safe for public environments – a metal back cover and intelligent heat management ensure safe use in public spaces where fire-retardancy is mandatory
- Enhanced imaging performance – advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images
- Mission-critical 24/7 ready operation – the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience
- Manufacturer
- Sharp
- Part number
- MA551-PT
- Condition
- New
- Category
- Input & Output Devices › Pointing Devices
Overview
Meticulously powerful signage
When true-to-life colour rendition is essential, the MA Series’ advanced feature set delivers calibrated precision, without compromise. For specialist applications, the wide colour gamut panel, SpectraView engine technology and 8K signal processing, positions the MA series at the high end of professional content delivery.
The MA series’ modular design includes Intel® Smart Display Module (Intel® SDM) technology integrated into the display, facilitating powerful media playback for the most intuitive signage creation and delivery. Featuring an integral audio amplifier, multi-picture mode technology and extensive connectivity including video out, the MA series offers versatile functionality for corporate signage and prestige retail applications.
Specifications
| LED backlighting type | Edge-LED |
|---|---|
| Display diagonal | 139.7 cm (55") |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | Yes |
| Touchscreen technology | Projected capacitive system |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 8000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Display diagonal (metric) | 138.8 cm |
| Horizontal scan range | 26 - 91.1 kHz |
| Vertical scan range | 23 - 86 Hz |
| Native refresh rate | 60 Hz |
| HDMI ports quantity | 3 |
|---|---|
| DVI port | No |
| DisplayPorts quantity | 3 |
| DisplayPorts in | 2 |
| DisplayPorts out | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio (L/R) out | 1 |
| RS-232 interface | Yes |
| Product design | Digital signage flat panel |
|---|---|
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 300 x 300 mm |
| Bezel width (bottom) | 1.56 cm |
| Bezel width (side) | 1.25 cm |
| Bezel width (top) | 1.2 cm |
| Purpose | Universal |
|---|---|
| Picture-in-Picture | Yes |
| Operating hours (hours/days) | 24/7 |
| International Protection (IP) code | IP5X, IP2X |
| Energy efficiency class (SDR) | G |
|---|---|
| Energy efficiency class (HDR) | G |
| Energy consumption (SDR) per 1000 hours | 106 kWh |
| Energy consumption (HDR) per 1000 hours | 99 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
| Computer system | No |
|---|---|
| Built-in processor | No |
| Width | 1239.6 mm |
|---|---|
| Depth | 61.1 mm |
| Height | 713 mm |
| Weight | 27.6 kg |
| Package width | 1430 mm |
|---|---|
| Package depth | 250 mm |
| Package height | 920 mm |
| Package weight | 37.7 kg |
| Remote control included | Yes |
|---|---|
| Cables included | AC, HDMI |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Harmonized System (HS) code | 85285210 |
|---|
| Ambient light sensor | Yes |
|---|
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 100 Mbit/s |
| Wi-Fi | No |
| Wall mountable | Yes |
|---|
| Sustainability certificates | ENERGY STAR |
|---|
