NEC Direct view LED (DVLED) Indoor
Part number LED-E012I-108
108IN DVLED 1.2MM PITCH VID WALL
- Low-profile integration – the super slim and light weight modules align with perfection to create a large digital canvas which integrates unobtrusively into any environment
- Front serviceable modules – with front access to the LED modules, maintenance is easy
- Slim design – with a flush rear profile, LED modules can be integrated very close to the wall with minimal gap necessary due to very low heat emission
- Care-free installation – with bundled solutions that deliver all you need to get your LED video wall up and running
- Manufacturer
- Sharp
- Part number
- LED-E012I-108
- Condition
- New
- Category
- Displays › Direct View Displays
- 1GPA category
- Hardware
Overview
Large Image Presentation, Small Budget Preservation
Bringing all the advantages of fine-pitch LED to more cost-conscious applications in corporate meeting rooms and digital signage, the E series lacks nothing in high impact content delivery. The pre-bundled solution includes everything you need to implement large surface visualisation without hindrance from bezels, with superb brightness and high contrast which gets noticed even in areas of high ambient light.
Designed for quick and easy set-up, the product is light weight and super slim for unobtrusive integration either free-standing or wall mounted. Front serviceable, all components are easily accessed for maintenance.
As you would expect from a quality manufacturer, there is no compromise to reliability, longevity and safety in offering this low-cost solution. Consistent with all LED products from Sharp/NEC, the chassis is of metal construction.
Specifications
| Display technology | Direct view LED (DVLED) |
|---|---|
| Display diagonal | 2.74 m (108") |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Aspect ratio | 16:9 |
| Pixel pitch | 1.2 x 1.2 mm |
| Display brightness | 600 cd/m² |
| Display number of colours | 281 trillion colours |
| Colour temperature (min) | 3000 K |
| Colour temperature (max) | 9500 K |
| Contrast ratio (typical) | 5000:1 |
| Native refresh rate | 3840 Hz |
| Display refresh rates supported | 50 Hz, 60 Hz |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
| Colour depth | 16 bit |
| Panel life | 100000 h |
| Display diagonal (metric) | 274 cm |
| Dimming capability (levels) | 256 |
| Placement supported | Indoor |
|---|---|
| Orientation | Horizontal |
| Front maintenance | Yes |
| International Protection (IP) code | IP20 |
| Product colour | Black |
| Panel material | Aluminium |
| HDMI ports quantity | 1 |
|---|---|
| HDMI input ports quantity | 1 |
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| SDI inputs | 1 |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Power consumption (typical) | 944 W |
|---|---|
| Power consumption (max) | 2000 W |
| Operating temperature (T-T) | -20 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Compliance certificates | CE, ETL, Federal Communications Commission (FCC), RoHS |
|---|
| Sustainability compliance | Yes |
|---|
| Width | 2412 mm |
|---|---|
| Depth | 47 mm |
| Height | 1456 mm |
| Weight | 91.2 kg |
| Module depth | 2.9 cm |
| Module width | 60 cm |
| Module height | 33.8 cm |
| Video wall controller included | Yes |
|---|---|
| Mounting kit | Yes |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
