QNAP TS-H1065EU Storage server Rack (2U) 8 GB DDR5 0 TB QNAP QTS Black
Part number TS-H1065EU-8G-US
2U 8-BAY SHORT-DEPTH RACKMOUNT INTEL 4-CORE CPU 8GB DDR5 SODIMM
Flexible E1.S/M.2 slots: Two built-in E1.S/M.2 NVMe PCIe slots allow flexible configuration of SSD caching or installation of the QXG-ES10G1T network module, ensuring the NAS is never limited in its specifications
DDR5 RAM: Built-in high-performance and low power consumption DDR5 RAM supports In-Band ECC (IBECC) for data reliability. Up to 16GB RAM can be installed
Built-in QuTS hero operating system: Utilizing the ZFS file system, it provides data protection features such as self-healing of static data, WORM, data deduplication, and snapshot backups, ensuring data integrity and system stability
Dual 2.5GbE as standard: Accelerate data transfer and backup speeds by enabling Port Trunking or SMB Multichannel
PCIe Gen 3 slot: Supports 5/10GbE NIC or QM2 expansion cards, offering flexible upgrades for high-speed networking and enhanced application performance
Long-term supply: TS-h1065eU will be available and supported by QNAP for an extended period, up to 2031
Manufacturer
QNAP INC
Part number
TS-H1065EU-8G-US
Condition
New
Category
Network Devices › Servers
1GPA category
Hardware
Overview
TS-h1065eU
2U short-depth NAS equipped with advanced E1.S/M.2 PCIe NVMe slots and expandable with 10GbE connectivity
TS-h1065eU is designed for small and medium-sized businesses. Its 2U short-depth rackmount design makes it ideal for deployment in space-constrained environments. TS-h1065eU is powered by an Intel® quad-core processor, delivering 8 × 3.5-inch SATA drive bays, two highly expandable E1.S/M.2 PCIe NVMe slots—all within a compact 30 cm (12-inch) chassis. This combination of features is unmatched by competitors, making it a high-performance and highly efficient NAS solution for multitasking workloads.
Specifications
Storage
Storage drive capacity
0 GB
Supported storage drive interfaces
Serial ATA III, M.2
Storage drive sizes supported
3.5,E1.S,M.2
RAID support
Yes
RAID levels
0, 1, 5, 6, 10, 50, JBOD
Online RAID migration
Yes
Online RAID expansion
Yes
RAID rebuild
Yes
Hot-swap drive bays
Yes
Supported file systems
ext4, ext3, HFS+, FAT32, exFAT
Storage drives installed
No
Total installed storage capacity
0 TB
Number of storage drives supported
10
Installed storage drive type
No
Supported storage drive types
SSD
Auto-rebuild
Yes
Bad block scan
Yes
Disk roaming
Yes
Processor
Processor manufacturer
Intel
Processor cores
4
Memory
Internal memory
8 GB
Internal memory type
DDR5
Maximum RAM supported
16 GB
Memory slots
1
Memory form factor
SO-DIMM
Flash memory
4000 MB
Network
Ethernet LAN
Yes
Ethernet LAN data rates
2500,1000,100,10 Mbit/s
DHCP server
Yes
Jumbo frames support
Yes
Wake-on-LAN ready
Yes
Ports & interfaces
USB port
Yes
USB 2.0 ports quantity
3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
Ethernet LAN (RJ-45) ports
2
Design
Chassis type
Rack (2U)
Cooling type
Active
Product colour
Black
LED indicators
Yes
Performance
Type
Storage server
Device class
Home & Home Office
Backup function
Yes
Buzzer
Yes
Reset button
Yes
On/off switch
Yes
Disk scan
Yes
S.M.A.R.T. support
Yes
Software
Operating system installed
QNAP QTS
Operating system version
5.2.9
Power
Power supply location
Built-in
Power supply unit (PSU) capacity
250 W
Number of power supply units
1
Power consumption (typical)
55.83 W
Power consumption (HDD standby)
31.742 W
AC input voltage
100 - 240 V
Weight & dimensions
Width
432 mm
Depth
294.9 mm
Height
88.6 mm
Package width
530 mm
Package depth
210 mm
Package height
592 mm
Package weight
8.3 kg
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
5 - 95%
Storage temperature (T-T)
-20 - 70 °C
Storage relative humidity (H-H)
5 - 95%
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
