Opengear
Opengear CM8132-10G-C console server USB
Part number CM8132-10G-C
32 SERIAL PORTS, 2X 10GBE SFP+, 2X 1GBE, ARM 1.6GHZ 2-CORE 2GB MEM 32GB FLASH, T
- Secure, remote, access to manage up to 96 serial devices
- Connect to high-speed networks via 10G SFP+ uplinks
- Simplify configuration with the auto-port discovery
- Reduce cable clutter with software-selectable serial ports
- Global cellular modem for cellular resiliency
- Manufacturer
- Opengear
- Part number
- CM8132-10G-C
- Condition
- New
- Category
- Network Devices › Servers
- 1GPA category
- Hardware
Overview
CM8100-10G, used with our Lighthouse software, is the newest addition to Opengear's Network Resilience platform.
Specifications
| Mobile network generation | 5G |
|---|---|
| Rack mounting | Yes |
| MIB support | Yes |
| Internal modem | Yes |
| Cellular | Yes |
| Zero Touch Provisioning (ZTP) | Yes |
| Web-based management | Yes |
| Temperature sensor | Yes |
| 4G LTE | Yes |
| Product colour | Black, Red |
| Security algorithms | TACACS+, WPA-RADIUS, IPSec |
|---|
| Console port | USB |
|---|---|
| Serial ports quantity | 8 |
| Ethernet LAN (RJ-45) ports | 2 |
| SFP module slots quantity | 2 |
| Compliance certificates | RoHS |
|---|
| Dimensions (WxDxH) | 220 x 177 x 44 mm |
|---|---|
| Weight | 1.55 kg |
| Package height | 44 mm |
| Package length | 44 cm |
| Package width | 256 mm |
| Package weight | 3.5 kg |
| Power source type | DC |
|---|---|
| AC input voltage | 110-240 V |
| AC input frequency | 50-60 Hz |
| DC input voltage | 40-72 V |
| Number of power supply units | 2 |
| Operating temperature (T-T) | 5 - 50 °C |
|---|---|
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| RAM capacity | 2048 MB |
|---|---|
| RAM type | DDR4 |
| eMMC capacity | 32 GB |
| Processor family | ARM Cortex-A9 |
|---|---|
| Processor model | A9 |
| Processor cores | 2 |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
