Opengear ACM7008-2-GLB
Opengear

Opengear ACM7008-2-GLB gateway/controller 10, 100, 1000 Mbit/s

Part number ACM7008-2-GLB

8 SERIAL STRAIGHT PINOUT2 GBE ETH 4 USB CONSOLE PT2DIO2 OUTPUT

  • 4-8 serial ports, out-of-band management of network and server devices
  • 4 x USB 2.0 console ports, out-of-band management of network and server devices
Manufacturer
Opengear
Part number
ACM7008-2-GLB
Term
Per Ingram SKU US5525
Condition
New
Category
Network Devices › Servers
1GPA category
Hardware

Overview

For small IT deployments at edge locations, the Resilience Gateway provides secure remote access to your critical devices via Smart Out-of-Band management. An embedded, global 4G-LTE cellular modem offers an alternate path when the primary link is unavailable.

Connect devices directly to this small form-factor console server via 8 serial and 4 USB ports, providing always-on access to your remote networking equipment. Every model includes 4GB internal memory. Options include a 4-port GbE switch and models without the cellular modem.

Part of the Opengear Network Resilience Platform, the ACM7000 Resilience Gateway with Lighthouse management software and Failover to Cellular™ is used at small Retail locations, Bank branches/ATMs, regional offices, and at many other remote locations where business continuity is critical.

The ‘-GLB’ suffix indicates the unit ships with a 12V global power supply.

Specifications

Design
Product colourBlack, Red
Mounting typeRack mounting
LED indicatorsYes
Performance
Built-in processorYes
Processor frequency800 MHz
Number of processors installed1
Internal memory256 MB
Internal memory typeDDR
Flash memory4032 MB
Protocols
Management protocolsHTTPS, SSH, Nagios NSCA, NRPE, SNMP, TFTP & FTP
DHCP serverYes
Network
Ethernet LAN data rates10,100,1000 Mbit/s
Data transfer rate1000 Gbit/s
Dynamic DNS (DDNS)Yes
Security
Firewall securityYes
Authentication methodRADIUS, LDAP, PAP/CHAP
Ports & interfaces
Interface8x RS-232 (RJ45), 4x USB, 2x DIO, 2x HVDO
USB 2.0 ports quantity4
Ethernet LAN (RJ-45) ports2
WAN connectionEthernet (RJ-45)
Management features
Web-based managementYes
SyslogYes
Power
Power consumption (typical)11.5 W
Input voltage110 - 240 V
Output voltage12 V
Weight & dimensions
Weight600 g
Dimensions (WxDxH)130 x 120 x 35 mm
Packaging content
AC adapter includedYes
Cables includedAC
Quick installation guideYes
Operational conditions
Operating temperature (T-T)5 - 50 °C
Operating relative humidity (H-H)5 - 90%
Technical details
Electromagnetic compatibilityEN 55022:2010, CISPR 22:2008, FCC Part 15 Subpart B:2015, ICES-003 Issue 5 (2014), AS/NZS CISPR 22:2009+A1:2010, EN 61000-3-2:2006/A2:2009, EN 61000-3-3:2008, EN 55024:2010, CISPR 24:2010, EN 61000-4-2:2009, EN 61000-4-3:2006+A2:2010, EN 61000-4-4:2004+A1:2010, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-8:2010, EN 61000-4-11:2004

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
