Overview
The MAG series fights alongside gamers in pursuit of honor.
With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.
Specifications
Display
| Display diagonal | 68.6 cm (27") |
|---|
| Display resolution | 3840 x 2160 pixels |
|---|
| HD type | 4K Ultra HD |
|---|
| Native aspect ratio | 16:9 |
|---|
| Panel type | IPS |
|---|
| Touchscreen | No |
|---|
| Display brightness (typical) | 400 cd/m² |
|---|
| Response time | 1 ms |
|---|
| Screen shape | Flat |
|---|
| Supported graphics resolutions | 3840 x 2160 |
|---|
| Supported video modes | 2160p |
|---|
| Aspect ratio | 16:9 |
|---|
| Contrast ratio (typical) | 1000:1 |
|---|
| Contrast ratio (dynamic) | 100000000:1 |
|---|
| Maximum refresh rate | 144 Hz |
|---|
| Viewing angle, horizontal | 178° |
|---|
| Viewing angle, vertical | 178° |
|---|
| Display number of colours | 1.07 billion colours |
|---|
| Pixel pitch | 0.1554 x 0.1554 mm |
|---|
| Horizontal scan range | 106.7 - 320 kHz |
|---|
| Vertical scan range | 48 - 144 Hz |
|---|
| Viewable size, horizontal | 59.7 cm |
|---|
| Viewable size, vertical | 33.6 cm |
|---|
| Display diagonal (metric) | 69 cm |
|---|
| Colour gamut standard | DCI-P3 |
|---|
| Colour gamut | 98% |
|---|
| sRGB coverage (typical) | 129% |
|---|
Performance
| NVIDIA G-SYNC | No |
|---|
| AMD FreeSync | Yes |
|---|
| AMD FreeSync type | FreeSync Premium |
|---|
Design
| Market positioning | Gaming |
|---|
| Product colour | Black |
|---|
| Frameless design | Yes |
|---|
Ports & interfaces
| Built-in USB hub | Yes |
|---|
| USB hub version | 2.0 |
|---|
| USB upstream port type | USB Type-B |
|---|
| USB Type-A downstream ports quantity | 2 |
|---|
| USB Type-C DisplayPort Alternate Mode | Yes |
|---|
| DVI port | No |
|---|
| HDMI | Yes |
|---|
| HDMI ports quantity | 2 |
|---|
| HDMI version | 2.1 |
|---|
| DisplayPorts quantity | 1 |
|---|
| DisplayPort version | 1.4a |
|---|
| Headphone out | Yes |
|---|
| Headphone outputs | 1 |
|---|
Ergonomics
| VESA mounting | Yes |
|---|
| Panel mounting interface | 75 x 75 mm |
|---|
| Cable lock slot | Yes |
|---|
| Cable lock slot type | Kensington |
|---|
| Height adjustment | Yes |
|---|
| Adjustable height (max) | 13 cm |
|---|
| Pivot | Yes |
|---|
| Pivot angle | -90 - 90° |
|---|
| Swivelling | Yes |
|---|
| Swivel angle range | -45 - 45° |
|---|
| Tilt adjustment | Yes |
|---|
| Tilt angle range | -5 - 20° |
|---|
Power
| Energy efficiency class (SDR) | F |
|---|
| Energy efficiency class (HDR) | G |
|---|
| Energy consumption (SDR) per 1000 hours | 26 kWh |
|---|
| Energy consumption (HDR) per 1000 hours | 47 kWh |
|---|
| Power consumption (typical) | 26 W |
|---|
| Power consumption (standby) | 0.5 W |
|---|
| Power consumption (off) | 0.3 W |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50/60 Hz |
|---|
| Input current | 6.32 A |
|---|
| AC adapter output voltage | 19 V |
|---|
| Power supply type | External |
|---|
| Energy efficiency scale | A to G |
|---|
Weight & dimensions
| Width (with stand) | 613.5 mm |
|---|
| Depth (with stand) | 196.5 mm |
|---|
| Height (with stand) | 402.1 mm |
|---|
| Weight (with stand) | 6.05 kg |
|---|
| Width (without stand) | 613.5 mm |
|---|
| Depth (without stand) | 69.8 mm |
|---|
| Height (without stand) | 362.5 mm |
|---|
| Weight (without stand) | 4.05 kg |
|---|
Packaging data
| Package width | 830 mm |
|---|
| Package depth | 158 mm |
|---|
| Package height | 526 mm |
|---|
| Package weight | 8.1 kg |
|---|
