Overview
The MSI ARSENAL GAMING (MAG) series is engineered to give gamers the edge they need to dominate on the virtual battlefield. Inspired by the rugged durability and unwavering reliability of military-grade equipment, the MAG series is built to provide an unwavering defense in every gaming scenario.
However, MAG isn't just about performance; it's a design language that conveys ruggedness and toughness, embodying the very essence of the MAG style. For gamers who are determined to dominate their digital battlegrounds, the MAG series is here to stand with you, establishing the ultimate defense.
Specifications
Display
| Display diagonal | 68.6 cm (27") |
|---|
| Display resolution | 2560 x 1440 pixels |
|---|
| HD type | Wide Quad HD |
|---|
| Native aspect ratio | 16:9 |
|---|
| Panel type | Rapid VA |
|---|
| Touchscreen | No |
|---|
| Display brightness (typical) | 300 cd/m² |
|---|
| Response time | 0.5 ms |
|---|
| Response time measurement type | GTG (Gray to Gray) |
|---|
| Anti-glare screen | Yes |
|---|
| Screen shape | Curved |
|---|
| Screen curvature rating | 1500R |
|---|
| Supported graphics resolutions | 2560 x 1440 |
|---|
| Supported video modes | 1440p |
|---|
| Contrast ratio (typical) | 5000:1 |
|---|
| Contrast ratio (dynamic) | 100000000:1 |
|---|
| Maximum refresh rate | 180 Hz |
|---|
| Viewing angle, horizontal | 178° |
|---|
| Viewing angle, vertical | 178° |
|---|
| Display number of colours | 1.07 billion colours |
|---|
| Horizontal scan range | 71.04 - 266.4 kHz |
|---|
| Vertical scan range | 48 - 180 Hz |
|---|
| Viewable size, horizontal | 59.7 cm |
|---|
| Viewable size, vertical | 33.6 cm |
|---|
| Display diagonal (metric) | 68.58 cm |
|---|
| High Dynamic Range (HDR) supported | Yes |
|---|
| Colour depth | 10 bit |
|---|
| Colour gamut standard | DCI-P3 |
|---|
| Colour gamut | 93% |
|---|
| sRGB coverage (typical) | 128% |
|---|
Performance
| NVIDIA G-SYNC | No |
|---|
| AMD FreeSync | No |
|---|
Multimedia
| Built-in speaker(s) | No |
|---|
| Built-in camera | No |
|---|
Design
| Market positioning | Gaming |
|---|
| Product colour | Black |
|---|
| Frameless design | Yes |
|---|
Ports & interfaces
| Built-in USB hub | No |
|---|
| DVI port | No |
|---|
| HDMI | Yes |
|---|
| HDMI ports quantity | 2 |
|---|
| HDMI version | 2.0b |
|---|
| DisplayPorts quantity | 1 |
|---|
| DisplayPort version | 1.4 |
|---|
| Audio input | No |
|---|
| Headphone out | Yes |
|---|
| Headphone outputs | 1 |
|---|
Ergonomics
| VESA mounting | Yes |
|---|
| Panel mounting interface | 100 x 100 mm |
|---|
| Cable lock slot | Yes |
|---|
| Cable lock slot type | Kensington |
|---|
| Height adjustment | No |
|---|
| Tilt adjustment | Yes |
|---|
| Tilt angle range | -5 - 20° |
|---|
Power
| Energy efficiency class (SDR) | F |
|---|
| Energy efficiency class (HDR) | G |
|---|
| Energy consumption (SDR) per 1000 hours | 25 kWh |
|---|
| Energy consumption (HDR) per 1000 hours | 40 kWh |
|---|
| Power consumption (standby) | 0.5 W |
|---|
| Power consumption (off) | 0.3 W |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50/60 Hz |
|---|
| Input current | 2.25 A |
|---|
| AC adapter output voltage | 20 V |
|---|
| Power supply type | External |
|---|
| Energy efficiency scale | A to G |
|---|
Weight & dimensions
| Width (with stand) | 614 mm |
|---|
| Depth (with stand) | 250 mm |
|---|
| Height (with stand) | 438 mm |
|---|
| Weight (with stand) | 3.4 kg |
|---|
| Width (without stand) | 614 mm |
|---|
| Depth (without stand) | 77 mm |
|---|
| Height (without stand) | 364 mm |
|---|
| Weight (without stand) | 3 kg |
|---|
Packaging data
| Package width | 765 mm |
|---|
| Package depth | 165 mm |
|---|
| Package height | 515 mm |
|---|
| Package weight | 6.1 kg |
|---|
| Package type | Box |
|---|
Other features
| Warranty period | 3 year(s) |
|---|
Technical details
| Native refresh rate | 60 Hz |
|---|
