Overview
The MSI ARSENAL GAMING (MAG) series is engineered to give gamers the edge they need to dominate on the virtual battlefield. Inspired by the rugged durability and unwavering reliability of military-grade equipment, the MAG series is built to provide an unwavering defense in every gaming scenario.
However, MAG isn't just about performance; it's a design language that conveys ruggedness and toughness, embodying the very essence of the MAG style. For gamers who are determined to dominate their digital battlegrounds, the MAG series is here to stand with you, establishing the ultimate defense.
Specifications
Display
| Display diagonal | 62.2 cm (24.5") |
|---|
| Display resolution | 1920 x 1080 pixels |
|---|
| HD type | Full HD |
|---|
| Native aspect ratio | 16:9 |
|---|
| Panel type | Rapid IPS |
|---|
| Touchscreen | No |
|---|
| Display brightness (typical) | 250 cd/m² |
|---|
| Response time | 0.5 ms |
|---|
| Response time measurement type | GTG (Gray to Gray) |
|---|
| Display surface | Matt |
|---|
| Screen shape | Flat |
|---|
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
|---|
| Supported video modes | 1080p |
|---|
| Aspect ratio | 16:9 |
|---|
| Contrast ratio (typical) | 1000:1 |
|---|
| Contrast ratio (dynamic) | 100000000:1 |
|---|
| Maximum refresh rate | 300 Hz |
|---|
| Viewing angle, horizontal | 178° |
|---|
| Viewing angle, vertical | 178° |
|---|
| Display number of colours | 1.07 billion colours |
|---|
| Pixel pitch | 0.2832 x 0.2802 mm |
|---|
| Horizontal scan range | 53.28 - 333 kHz |
|---|
| Vertical scan range | 48 - 900 Hz |
|---|
| Viewable size, horizontal | 54.4 cm |
|---|
| Viewable size, vertical | 30.3 cm |
|---|
| Display diagonal (metric) | 62.23 cm |
|---|
| High Dynamic Range (HDR) supported | Yes |
|---|
| Colour depth | 8 bit |
|---|
| Colour gamut standard | DCI-P3 |
|---|
| Colour gamut | 90% |
|---|
Performance
| NVIDIA G-SYNC | No |
|---|
| AMD FreeSync | Yes |
|---|
| AMD FreeSync type | FreeSync Premium |
|---|
| Flicker-free technology | Yes |
|---|
| Low Blue Light technology | Yes |
|---|
Multimedia
| Built-in speaker(s) | No |
|---|
| Built-in camera | No |
|---|
Design
| Market positioning | Gaming |
|---|
| Product colour | Black |
|---|
| Frameless design | Yes |
|---|
| Feet colour | Black |
|---|
Ports & interfaces
| Built-in USB hub | No |
|---|
| DVI port | No |
|---|
| HDMI | Yes |
|---|
| HDMI ports quantity | 2 |
|---|
| HDMI version | 2.0 |
|---|
| DisplayPorts quantity | 1 |
|---|
| DisplayPort version | 1.4a |
|---|
| Audio input | No |
|---|
| Headphone out | Yes |
|---|
| Headphone outputs | 1 |
|---|
Ergonomics
| VESA mounting | Yes |
|---|
| Panel mounting interface | 100 x 100 mm |
|---|
| Cable lock slot | Yes |
|---|
| Cable lock slot type | Kensington |
|---|
| Height adjustment | No |
|---|
| Tilt adjustment | Yes |
|---|
| Tilt angle range | -5 - 20° |
|---|
| On Screen Display (OSD) | Yes |
|---|
Power
| Energy efficiency class (SDR) | E |
|---|
| Energy efficiency class (HDR) | G |
|---|
| Energy consumption (SDR) per 1000 hours | 18 kWh |
|---|
| Energy consumption (HDR) per 1000 hours | 25 kWh |
|---|
| Power consumption (standby) | 0.5 W |
|---|
| Power consumption (off) | 0.3 W |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50/60 Hz |
|---|
| Power supply type | Internal |
|---|
| Energy efficiency scale | A to G |
|---|
Weight & dimensions
| Width (with stand) | 557.1 mm |
|---|
| Depth (with stand) | 220.1 mm |
|---|
| Height (with stand) | 418.5 mm |
|---|
| Weight (with stand) | 3.24 kg |
|---|
| Width (without stand) | 557.1 mm |
|---|
| Depth (without stand) | 66.4 mm |
|---|
| Height (without stand) | 326.9 mm |
|---|
Packaging data
| Package weight | 5.13 kg |
|---|
| Package type | Box |
|---|
Other features
| On/off switch | Yes |
|---|
| TV tuner integrated | No |
|---|
| Warranty period | 3 year(s) |
|---|
Technical details
| Native refresh rate | 300 Hz |
|---|
