MSI Cubi NUC 1M-010BUS 0.84L sized PC Black 120U Intel SoC
Part number CUBINUC1M010B
CUBI NUC 1M-010BUS BAREBONE/I5-120U/BLK/3YAR
- No OS
- Intel Core 5 120U (12MB Cache)
- Manufacturer
- MSI
- Part number
- CUBINUC1M010B
- Condition
- New
- Category
- Computer Systems › Barebones Systems
- 1GPA category
- Hardware
Overview
Resilient and Pioneering Spirit of Your Business
Your business should be empowered to stop at nothing while navigating your journey with MSI Business & Productivity Series products.
Built for Sustainability
The Cubi NUC Series blends business-centric design with environmental responsibility - an embodiment of MSI's dedication to sustainability. Our commitment extends to incorporating sustainable materials in both our product design and packaging, protecting the earth through our actions. By utilizing sustainable materials such as PCR plastics, recycled pulp from FSC™-certified forests, more active management of substances used in manufacturing processes, and the continued use of renewable energy in production processes, we ensure the products' durability and a commitment to a greener world.
The Cubi NUC Series embodies sustainable value and heightened productivity.
A Better Future with
EPEAT Registered MSI Desktops.
EPEAT is the world’s premier global ecolabel for electronics. MSI desktops provide sustainable products inside out and participate in EPEAT/EPEAT ecolabel. Let’s protect the earth with actions.
Specifications
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel Core 5 |
| Processor generation | Intel Core (Series 1) |
| Processor model | 120U |
| Processor cores | 10 |
| Processor threads | 12 |
| Processor boost frequency | 5 GHz |
| Performance cores | 2 |
| Efficient cores | 8 |
| Performance-core Max Turbo Frequency | 5 GHz |
| Efficient-core Max Turbo Frequency | 3.8 GHz |
| Performance-core base frequency | 1.4 GHz |
| Efficient-core base frequency | 0.9 GHz |
| Built-in processor | Yes |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Memory slots type | SO-DIMM |
|---|---|
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 5200 MHz |
| Supported memory types | DDR5-SDRAM |
| Supported storage drive types | HDD & SSD |
|---|---|
| Storage drive sizes supported | 2.5,M.2 |
| SSD form factor | M.2 |
| Storage drive interface | M.2 |
| NVMe | Yes |
| Number of storage drives supported | 3 |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| On-board graphics card | Yes |
|---|---|
| Graphics card family | Intel |
| On-board graphics card model | Intel® Graphics |
| Number of displays supported | 4 |
| Motherboard form factor | NUC |
|---|---|
| Motherboard chipset | Intel SoC |
| Number of processors supported | 1 |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Built-in speaker(s) | No |
|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
|---|---|
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| LAN controller | Intel I226-V |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
|---|---|
| HDMI ports quantity | 2 |
| HDMI version | 1.4b/2.1 |
| DVI port | No |
| Microphone in | No |
| Combo headphone/mic port | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Thunderbolt 4 ports quantity | 2 |
| DC-in jack | Yes |
| Number of M.2 (M) slots | 2 |
|---|
| Chassis type | 0.84L sized PC |
|---|---|
| Product colour | Black |
| Cooling type | Active |
| On/off switch | Yes |
| Housing material | Plastic |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Product type | Mini PC barebone |
| Certification | FCC(Class B), CB/CE, UL(CUL), BSMI, VCCI, RCM(C-Tick) |
|---|
| Operating system installed | No |
|---|
| Power supply type | External AC adapter |
|---|---|
| Power supply | 120 W |
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage relative humidity (H-H) | 0 - 90% |
| Width | 132.5 mm |
|---|---|
| Depth | 135.6 mm |
| Height | 50.1 mm |
| Weight | 0.625 g |
| Package width | 205 mm |
| Package depth | 220 mm |
| Package height | 94 mm |
| Package weight | 1.45 g |
| Power cord included | Yes |
|---|---|
| AC adapter included | Yes |
| Quick start guide | Yes |
| Display included | No |
| Mouse included | No |
| Keyboard included | No |
| Country of origin | China |
|---|---|
| Warranty period | 2 year(s) |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
