LG LSCC015 LED Indoor
Part number LSCC015-GZ
ULTRA SLIM LSCC 384X432 STNDRD PNL/CBNT 800 NIT
- Pixel Pitch: 1.56 mm
- Brightness: 800 nit (Max.)
- Ultra Slim Depth and Lightweight
- Flexible Design
- Manufacturer
- LG
- Part number
- LSCC015-GZ
- Condition
- New
- Category
- Displays › Large Format Displays
- 1GPA category
- Hardware
Overview
LSCC Direct View LED Customizable to fit your needs
For added installation flexibility, the LSCC series offers half-height/ half-width and curved cabinets to create various types of screens, including customized curvature, concave and convex configurations*.
Ultra Slim Depth
The LSCC Series’ ultra-slim cabinet design, with 33.6mm edge thickness, is its most significant advantage. This feature enables the LSCC Series to be installed and utilized in any type of venue without restriction.
Superior Energy Efficiency
The LSCC series improves power consumption by 16% to 25% depending on pitch models, delivering both energy efficiency and lower operating costs when compared to the LG LSCB model.
Specifications
| Display technology | LED |
|---|---|
| Display resolution | 384 x 216 pixels |
| HD type | 4K Ultra HD |
| Pixel pitch | 1.56 x 1.56 mm |
| Display brightness | 800 cd/m² |
| Contrast ratio (typical) | 5000:1 |
| Native refresh rate | 3840 Hz |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10), High Dynamic Range 10 Pro (HDR10 Pro) |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 160° |
| Placement supported | Indoor |
|---|---|
| Orientation | Horizontal |
| Number of modules included | 2 |
| International Protection (IP) code | IP30 |
| Product colour | Black |
| Purpose | Commercial |
| Power consumption (typical) | 37 W |
|---|---|
| Power consumption (max) | 112 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Heat dissipation | 382 BTU/h |
| Operating temperature (T-T) | -10 - 45 °C |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Compliance certificates | CE, ETL, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), REACH, RoHS |
|---|
| Certification | BS476 Part7 Class 1, EN13501-1 |
|---|
| Width | 600 mm |
|---|---|
| Depth | 33.6 mm |
| Height | 337.5 mm |
| Weight | 5 kg |
| Video wall controller included | Yes |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
