LG LSBE015-GD LED Indoor
Part number LSBE015-GD
LSBE DVLED P1.56 384X216 TAA SINGLE SMD 600 NIT
- LED
- 384 x 216 pixels
- 600 cd/m² 5000:1 1.56 x 1.56 mm
- Indoor Horizontal/Vertical Black
- Manufacturer
- LG
- Part number
- LSBE015-GD
- Condition
- New
- Category
- Displays › Large Format Displays
- 1GPA category
- Hardware
Overview
Improved Flatness and Easy Maintenance
LSBE utilizes two modules to form a single cabinet, which helps minimize the gaps between modules compared to cabinets composed of multiple modules resulting in a smoother screen with fewer visible gaps. Moreover thanks to its structural advantage, LSBE allows for easy maintenance.
Durable Frame Design
LSBE incorporates an aluminum cabinet that enhances durability, and its high-strength frame, surpassing that of plastic, allows for stable operation.
Brightness
With a great brightness of 600 nits, it clearly delivers content and attracts public attention, making it ideal for achieving bright indoor visibility.
Compatibility with LG Software Solutions
When connected with LG's CVBA system controller, the LSBE series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
* The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
* The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
* Actual GUI may vary in different webOS versions.
* LG Software solutions needs to be purchased separately.
Specifications
| Display technology | LED |
|---|---|
| Display resolution | 384 x 216 pixels |
| Native aspect ratio | 16:9 |
| Pixel pitch | 1.56 x 1.56 mm |
| Display brightness | 600 cd/m² |
| Contrast ratio (typical) | 5000:1 |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 150° |
| Colour depth | 14 bit |
| Placement supported | Indoor |
|---|---|
| Orientation | Horizontal/Vertical |
| International Protection (IP) code | IP50 |
| Product colour | Black |
| Purpose | Universal |
| DVI port | No |
|---|
| AC input voltage | 100 - 240 V |
|---|---|
| AC input frequency | 50/60 Hz |
| Operating temperature (T-T) | -20 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Compliance certificates | REACH, RoHS |
|---|
| Certification | CE, FCC, cTUVus, CB, KC, CCC |
|---|
| Display width | 600 mm |
|---|---|
| Display depth | 72 mm |
| Display height | 337.5 mm |
| Display weight | 6.5 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
