LG LAED015-GN Signage Display Digital signage flat panel 4.34 m (171") LED 500 cd/m² UltraWide Full HD Black
Part number LAED015-GN
171 AIO DVLED P1.6 INCL MOUNT REMOTE SPKR 500NIT
- Pixel Pitch : 1.56 mm
- Screen Size: 171”
- 21:9 Widescreen
- Embedded System Controller and Built-in Speaker
- Brightness (after calibration) : 500 nit (Max.)
- Manufacturer
- LG
- Part number
- LAED015-GN
- Condition
- New
- Category
- Displays › Direct View Displays
- 1GPA category
- Hardware
Overview
21:9 Widescreen
With support for a 21:9 widescreen aspect ratio (2,560 × 1,080), LAED series provides an immersive viewing experience with the wider screen than 16:9 display. Its screen specialization helps display 21:9 content including widescreen videoconferencing platforms with the natural details.
Easy Installation
The installation process of the 21:9 All-in-One series is simple. After securing three cabinets, attach each LED display module to them. Lastly, plug in the power cable. This simple installation saves time and labor, thereby makingusers handle the LED screen with ease.
Office Meeting Mode
With Office Meeting Mode, easily configure meeting room details like the room number and current time. It also includes convenient features like automatic input switching, a presentation timer, and adjustable settings such as autobrightness and picture mode.
Specifications
| Display diagonal | 4.34 m (171") |
|---|---|
| Display technology | LED |
| Display brightness | 500 cd/m² |
| HD type | UltraWide Full HD |
| Contrast ratio (typical) | 3000:1 |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 160° |
| Pixel pitch | 1.56 x 1.56 mm |
| Rated lifetime | 100000 h |
| HDMI ports quantity | 3 |
|---|---|
| DisplayPorts quantity | 1 |
| USB port | Yes |
| RS-232C | Yes |
| Remote (IR) input | 1 |
| Built-in speaker(s) | Yes |
|---|---|
| Number of built-in speakers | 2 |
| RMS rated power | 18 W |
| Product design | Digital signage flat panel |
|---|---|
| Product colour | Black |
| Purpose | Universal |
|---|---|
| International Protection (IP) code | IP30 |
| Power consumption (typical) | 311 W |
|---|---|
| Power consumption (standby) | 840 W |
| Power consumption (max) | 2100 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Heat dissipation | 7165 BTU/h |
| Computer system | Yes |
|---|---|
| Computer system type | System on Chip (SoC) |
| Display width | 4003 mm |
|---|---|
| Display depth | 36.5 mm |
| Display height | 1691 mm |
| Display weight | 176 kg |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Certification | CE,FCC,ETL,CB |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
