Specifications
Display
| Display technology | LED |
|---|
| Display resolution | 192 x 270 pixels |
|---|
| Pixel density | 90 ppi |
|---|
| Display brightness | 48 cd/m² |
|---|
| Contrast ratio (typical) | 4000:1 |
|---|
| Display refresh rates supported | 50 Hz, 60 Hz |
|---|
| Viewing angle, horizontal | 160° |
|---|
| Viewing angle, vertical | 160° |
|---|
| Colour depth | 16 bit |
|---|
| Service life of light source | 100000 h |
|---|
Design
| Placement supported | Indoor |
|---|
| Orientation | Horizontal/Vertical |
|---|
| Number of modules included | 6 |
|---|
| Frame material | Aluminium, Iron |
|---|
| Product colour | Black |
|---|
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
|---|
Power
| Power consumption (typical) | 90 W |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Operating relative humidity (H-H) | 10 - 80% |
|---|
Technical details
| Compliance certificates | CB, CE, ETL, REACH, RoHS, UL |
|---|
Weight & dimensions
| Width | 640 mm |
|---|
| Depth | 94 mm |
|---|
| Height | 900 mm |
|---|
| Weight | 2.65 kg |
|---|
