LG
LG GSCD125-GN video wall display LED Outdoor
Part number GSCD125-GN
12.5MM 5000NIT 3 IN 1 1000X1000X86.3MM
- 12.5 mm pixel pitch & 20,000:1 contrast ratio create stunning images
- 5,000 nits brightness for great outdoor visibility
- Ultra lightweight design for easy installation on buildings
- 90º corners to wrap around a building
- Durable design with IP65 rating
- 2 cabinet options
- Manufacturer
- LG
- Part number
- GSCD125-GN
- Condition
- New
- Category
- Displays › Direct View Displays
- 1GPA category
- Hardware
Overview
The cabinets of the GSCD series are much lighter than other outdoor LED displays weighing 46.7 lbs. & 41.88 lbs. This reduces the load on the building when a large LED screen is installed on it.
If you add a 90° corner option*, the GSCD series can deliver virtually flawless content even when installed on the corners.
The front and back of the cabinet are IP65 certified, allowing stable operation during bad weather and harmful outdoor environments.
Specifications
| Display technology | LED |
|---|---|
| Display resolution | 80 x 80 pixels |
| Pixel density | 6.4 ppi |
| LED backlighting type | SMD LED |
| Pixel pitch | 12.5 x 12.5 mm |
| Display brightness | 5000 cd/m² |
| Colour temperature (min) | 3200 K |
| Contrast ratio (typical) | 20000:1 |
| Native refresh rate | 3840 Hz |
| Display refresh rates supported | 3840 Hz, 50 Hz, 60 Hz |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10), High Dynamic Range 10 Pro (HDR10 Pro) |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 113° |
| Brightness uniformity | 0 - 97% |
| Grayscale depth | 14 bit |
| Panel life | 100000 h |
| Number of pixel per module | 40 x 20 |
| Placement supported | Outdoor |
|---|---|
| Orientation | Horizontal/Vertical |
| Number of modules (horizontal) | 2 |
| Frame material | Aluminium |
| Number of modules (vertical) | 4 |
| Front maintenance | Yes |
| Rear maintenance | Yes |
| International Protection (IP) code | IP65 |
| Power consumption (typical) | 220 W |
|---|---|
| Power consumption (max) | 660 W |
| AC input voltage | 100 to 240 |
| Heat dissipation | 2251.9 BTU/h |
| Operating temperature (T-T) | -30 - 50 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 99% |
| Compliance certificates | CE, ETL, Federal Communications Commission (FCC), RoHS |
|---|
| Width | 1000 mm |
|---|---|
| Depth | 86.3 mm |
| Height | 1000 mm |
| Weight | 19 kg |
| Module width | 50 cm |
| Module height | 25 cm |
| Module weight | 1.38 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
