Specifications
Display
| Display technology | LED |
|---|
| Pixel density | 20.736 ppi |
|---|
| LED backlighting type | SMD LED |
|---|
| Pixel pitch | 6.94 x 6.94 mm |
|---|
| Display brightness | 5000 cd/m² |
|---|
| Colour temperature (min) | 3200 K |
|---|
| Contrast ratio (typical) | 6000:1 |
|---|
| Native refresh rate | 3840 Hz |
|---|
| Display refresh rates supported | 3840 Hz, 50 Hz, 60 Hz |
|---|
| Viewing angle, horizontal | 160° |
|---|
| Viewing angle, vertical | 134° |
|---|
| Brightness uniformity | 0 - 97% |
|---|
| Grayscale depth | 16 bit |
|---|
| Number of pixel per module | 72 x 36 |
|---|
Design
| Placement supported | Outdoor |
|---|
| Orientation | Horizontal/Vertical |
|---|
| Number of modules (horizontal) | 2 |
|---|
| Frame material | Aluminium |
|---|
| Number of modules (vertical) | 4 |
|---|
| Front maintenance | Yes |
|---|
| Rear maintenance | Yes |
|---|
Power
| Power consumption (typical) | 226 W |
|---|
| Power consumption (max) | 680 W |
|---|
| AC input voltage | 100 - 240 V |
|---|
Operational conditions
| Operating temperature (T-T) | -30 - 50 °C |
|---|
| Operating relative humidity (H-H) | 10 - 99% |
|---|
Weight & dimensions
| Width | 1000 mm |
|---|
| Depth | 84.4 mm |
|---|
| Height | 1000 mm |
|---|
| Weight | 18.5 g |
|---|
| Module width | 50 cm |
|---|
| Module height | 25 cm |
|---|
| Module weight | 1.3 kg |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
