LG GSCD069-GN LED Outdoor
Part number GSCD069-GN.AUSQ
6.94MM 5000NIT 3IN1
- Pixel Pitch: 6.94mm
- Brightness: 5,000 cd/m²
- Lightweight Design
- IP65 Weatherproof Design
- 90º Corner Option Available
- Manufacturer
- LG
- Part number
- GSCD069-GN.AUSQ
- Condition
- New
- Category
- Displays › Direct View Displays
- 1GPA category
- Hardware
Overview
GSCD Ultra Light Series
With a lightweight design, the Ultra Light Series can be easily composed of a large screen without providing heavy load to the installing structure. A 90° corner option is provided for seamless right-angled installation.
Lightweight Design
The weights of the cabinet is very light, so even if a large LED screen is installed on the roof, it puts less pressure on the building's load.
Easy Maintenance
The control unit (PDU) of the cabinet is a modular type which can be easily attached or detached, supporting easy maintenance.
Front or Rear Serviceability
The product offers either front access or rear access, allowing customers to choose installation options according to their environment.
90° Corner Design Available
If you add a 90° corner option*, the GSCD series can deliver content effectively even when installed on the corners.
IP Rated Weatherproof Design
The front and back of the cabinet are IP65 certified, allowing stable operation less affected by weather.
Specifications
| Display technology | LED |
|---|---|
| Display resolution | 144 x 144 pixels |
| Active display area (W x H) | 1000 x 1000 mm |
| Pixel pitch | 6.94 x 6.94 mm |
| Display brightness | 5000 cd/m² |
| Contrast ratio (typical) | 6000:1 |
| Native refresh rate | 3840 Hz |
| Placement supported | Outdoor |
|---|---|
| Orientation | Horizontal/Vertical |
| International Protection (IP) code | IP65 |
| Product colour | Black |
| Purpose | Commercial |
| Power consumption (typical) | 226 W |
|---|---|
| AC input frequency | 50 - 60 Hz |
| Width | 1000 mm |
|---|---|
| Depth | 84.4 mm |
| Height | 1000 mm |
| Weight | 18.5 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
