LG GSCA046-GN LED Indoor/outdoor
Part number GSCA046-GN.AUSQ
4.63MM 5000NIT 3IN1 500X1000X68
- LED
- 108 x 216 pixels
- 5000 cd/m² 11000:1 3840 Hz 4.63 x 4.63 mm
- Indoor/outdoor Horizontal/Vertical
- 100 W
- Manufacturer
- LG
- Part number
- GSCA046-GN.AUSQ
- Condition
- New
- Category
- Displays › Direct View Displays
- 1GPA category
- Hardware
Overview
Fast Installation
Various factors including magnets on the top and bottom, positioning pins, handles and fast locks help installers easily set up and dismantle the LED screens without additional tools.
Easy Maintenance
The GSCA series applied a simple Lock Fixing method which requires no additional tools, making it easier to replace LED modules or power/data units. It saves cost and time for maintenance.
Two Cabinet Options
The GSCA series offers two sizes of cabinets enabling a screen size configuration that fits perfectly with customer's demands.
IP Rated Weatherproof & 90° Corner Design
The cabinet is IP65 certified, allowing stable operation unaffected by weather and harsh outdoor environments. Also, if you add a 90° corner option, the GSCA series can deliver flawless content even when installed on the corners.
Front or Rear Serviceability
The product offers either front access or rear access, allowing customers to choose installation options according to their environment and minimises limitations in installation and maintenance.
Specifications
| Display technology | LED |
|---|---|
| Display resolution | 108 x 216 pixels |
| Pixel density | 46.656 ppi |
| LED backlighting type | SMD LED |
| Pixel pitch | 4.63 x 4.63 mm |
| Display brightness | 5000 cd/m² |
| Colour temperature (min) | 3200 K |
| Contrast ratio (typical) | 11000:1 |
| Native refresh rate | 3840 Hz |
| Display refresh rates supported | 3840 Hz |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10), High Dynamic Range 10 Pro (HDR10 Pro) |
| Viewing angle, horizontal | 160° |
| Viewing angle, vertical | 135° |
| Brightness uniformity | 0 - 97% |
| Grayscale depth | 14 bit |
| Panel life | 100000 h |
| Number of pixel per module | 54 x 108 |
| Placement supported | Indoor/outdoor |
|---|---|
| Orientation | Horizontal/Vertical |
| Number of modules (horizontal) | 2 |
| Number of modules (vertical) | 2 |
| Front maintenance | Yes |
| Rear maintenance | Yes |
| International Protection (IP) code | IP65 |
| Power consumption (typical) | 100 W |
|---|---|
| Power consumption (max) | 300 W |
| AC input voltage | 100-240 V |
| Heat dissipation | 1023.6 BTU/h |
| Operating temperature (T-T) | -30 - 45 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 99% |
| Compliance certificates | CE, ETL, RoHS |
|---|
| Width | 500 mm |
|---|---|
| Depth | 67.2 mm |
| Height | 1000 mm |
| Weight | 12.7 kg |
| Module width | 25 cm |
| Module height | 50 cm |
| Module weight | 1.4 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
