LG CVCA video wall processor Black 50 W
Part number CVCA
4K CONTROLLER
- Manufacturer
- LG
- Part number
- CVCA
- Condition
- New
- Category
- Displays › Direct View Displays
- 1GPA category
- Hardware
Overview
CVCA LED Controller
Compatible with LAE, LAC, LBE, LBH, LBB, LSCA, LSBC, LSCC, LCCM, LFCG, GSCA, GSCD, GSCF, GMCA & GSPB LED Signage
webOS 4.0
Easily manage with LG ConnectedCare and SuperSign CMS
Specifications
| Product colour | Black |
|---|
| Maximum refresh rate | 60 Hz |
|---|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Internal memory | 8 GB |
| HDCP | Yes |
| HDCP version | 2.2 |
| Wi-Fi | Yes |
| Maximum resolution | 3840 x 2160 pixels |
| Bluetooth | Yes |
| HDMI input ports quantity | 1 |
|---|---|
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| RJ-45 ports quantity | 16 |
| USB 2.0 Type-A ports quantity | 1 |
| Power consumption (max) | 50 W |
|---|---|
| Input voltage | 100-240 V |
| Input frequency | 50/60 Hz |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Country of origin | China |
|---|
| Compliance certificates | KC, CB, Federal Communications Commission (FCC), CE |
|---|
| Width | 443 mm |
|---|---|
| Depth | 307.5 mm |
| Height | 63 mm |
| Weight | 4.9 kg |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
