LG 98UH5Q-H Signage Display Digital signage flat panel 2.49 m (98") LCD Wi-Fi 500 cd/m² 4K Ultra HD Black WebOS 24/7
Part number 98UH5Q-H
98IN LCD 4K MNTR 500 NIT WEBOS 8.0 WIFI BLUETOOTH
- Resolution : 3,840 × 2,160 (UHD)
- Anti-Glare Coating
- Surface Treatment (Haze) : 25%
- Bezel (Width / Depth) : 18 mm (Even) / 68.6 mm
- Operation Time : 24 Hours / 7 Days
- Manufacturer
- LG
- Part number
- 98UH5Q-H
- Condition
- New
- Category
- Displays › Large Format Displays
- 1GPA category
- Hardware
Overview
UHD Large Screen Signage Display with LG webOS Platform
Clear Visibility with Anti-Glare Coating
With an anti-glare coating and a brightness level of 500 cd/m², content remains clear and vivid even in bright environments.
High-Performance with webOS
LG webOS platform enhances user convenience with intuitive GUI and simple app development tools.
Slim Design
Being slim, a closer installation to the wall is advised. Additionally, this increases the screen’s immersive experience and provides a sophisticated design, improving the installed-space’s décor.
EMC Certified
With EMC Class B certification, the UH5Q series meets standards for electromagnetic emissions, supporting safety for both the environment and human health.
Versatile Operation with Multi-USB
With support for two USB ports, the UH5Q offers versatile usage options. For example, operating content on the screen while simultaneously using other connected devices is possible. This includes convenient tasks like downloading PPT files from external storage devices while using a mouse or keyboard during a meeting.
SuperSign Solutions
SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
Specifications
| Panel type | ADS |
|---|---|
| LED backlight | Yes |
| LED backlighting type | Direct-LED |
| Display diagonal | 2.49 m (98") |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 1000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Panel life | 50000 h |
| Native refresh rate | 60 Hz |
| Haze rate | 25% |
| HDMI ports quantity | 3 |
|---|---|
| Consumer Electronics Control (CEC) | Yes |
| DVI port | No |
| USB port | Yes |
| USB ports quantity | 2 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232C | Yes |
| Audio Return Channel (ARC) | Yes |
| Built-in speaker(s) | Yes |
|---|---|
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Product design | Digital signage flat panel |
|---|---|
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 800 x 400 mm |
| Bezel width (bottom) | 1.8 cm |
| Bezel width (side) | 1.8 cm |
| Bezel width (top) | 1.8 cm |
| Anti-glare screen | Yes |
| Purpose | Universal |
|---|---|
| Operating hours (hours/days) | 24/7 |
| Power consumption (typical) | 285 W |
|---|---|
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 385 W |
| Power consumption (economy mode) | 200 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Internal memory | 8 GB |
|---|---|
| Operating system installed | WebOS |
| Operating system version | 6.1 |
| Display width | 2198.9 mm |
|---|---|
| Display depth | 68.6 mm |
| Display height | 1254.6 mm |
| Display weight | 53.6 kg |
| Package width | 2360 mm |
|---|---|
| Package depth | 280 mm |
| Package height | 1425 mm |
| Package weight | 83.9 kg |
| Remote control included | Yes |
|---|---|
| Cables included | Power, Phone |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Gyroscope | Yes |
|---|---|
| Temperature sensor | Yes |
| Ethernet LAN | Yes |
|---|---|
| Wi-Fi | Yes |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
