LG 86IN LCD 3840X2160 4K MNTR 2.18 m (86") LED Wi-Fi 700 cd/m² 4K Ultra HD Black WebOS 24/7
Part number 86UH7N-M
HDMI IN , DP IN , RS-232C IN (4 PIN PHONE-JACK), RJ45 (LAN) IN, IR IN, USB IN US
- Resolution : 3,840 × 2,160 (UHD)
- Brightness : 700 nits (Typ.)
- The product carbon footprint of this product has been verified by the Carbon Trust.
- Surface Treatment (Haze) : 25%
- Manufacturer
- LG
- Part number
- 86UH7N-M
- Condition
- New
- Category
- Displays › Large Format Displays
- 1GPA category
- Hardware
Overview
Large UHD Signage Display with LG webOS Platform and Advanced Security
High Brightness
The digital signage display UH7N-M , with a great brightness of 700 nits, clearly delivers content even in bright stores.
Sturdy Design with Fire Flame Resistance
The outer cover of the digital signage display UH7N-M is designed to effectively resist fire flame spread, making the product a great fit for installation in public spaces.
Eye-catching Large Screen
A large screen effectively captures people's attention. Especially, 86-inch UH7N model supports 120Hz, enabling smooth content operation.
Versatile Operation with Multi-USB
With support for two USB ports, digital signage display UH7N-M offers versatile usage options. For example, operating content on the screen while simultaneously using other connected devices is possible. This includes convenient tasks like downloading PPT files from external storage devices while using a mouse or keyboard during a meeting.
High Resolution Display
The digital signage display UH7N-M offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.
Convenient webOS Platform
The 700 nits digital signage UH7N-M is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.
Durability that Provides Reliability
Optimized for business environments, the The digital signage display UH7N-M is guarded against the potential impact of salt, dust, iron powder and humidity through the implementation of conformal coating on the power board. Also, its customer-centric features, such as IP5x, 30-degree tilting and Shock Monitoring, provide both reliability and satisfaction.
Design for Space Utilization
Designed with thin bezels and simple cable management, the 700 nits digital signage UH7N-M saves space.
Enhanced Security Features
The digital signage display UH7N-M provides security features, including LG's Enhanced Kernel Protection (EKP) technology, guarding important data from external access or attacks. LG UHD Signage also holds reliable certification in the field of information security, maintaining customers' data and businesses securely. For example, UH7N-M is ISO/IEC 15408 Common Criteria EAL2 Certified.
SuperSign Solutions
SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
Carbon Footprint Verification
The cradle-to-grave carbon footprint of UH7N-M has been verified by the Carbon Trust.
Specifications
| Panel type | ADS |
|---|---|
| LED backlight | Yes |
| LED backlighting type | Edge-LED |
| Display diagonal | 2.18 m (86") |
| Display technology | LED |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 700 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 1000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Native refresh rate | 120 Hz |
| Haze rate | 25% |
| HDMI ports quantity | 2 |
|---|---|
| Consumer Electronics Control (CEC) | Yes |
| DVI port | No |
| DisplayPorts quantity | 1 |
| USB port | Yes |
| USB ports quantity | 3 |
| USB version | 2.0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio (L/R) out | 1 |
| RS-232C | Yes |
| Remote (IR) input | 1 |
| Built-in speaker(s) | Yes |
|---|---|
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Placement supported | Indoor |
|---|---|
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Bezel width (bottom) | 1.34 cm |
| Bezel width (side) | 1.34 cm |
| Bezel width (top) | 1.34 cm |
| Bezel colour | Black |
| Purpose | Commercial |
|---|---|
| Digital Rights Management (DRM) type | Pro:Idiom |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| HDCP version | 1.4/2.2 |
| Screen sharing | Yes |
| webRTC support | Yes |
| Power consumption (typical) | 205 W |
|---|---|
| Power consumption (off) | 0.5 W |
| Power consumption (max) | 297 W |
| Power consumption (economy mode) | 144 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
| Heat generation (typical) | 699 BTU/h |
| Heat generation (max) | 1013 BTU/h |
| Internal memory | 16 GB |
|---|---|
| Operating system installed | WebOS |
| Operating system version | 6.0 |
| Base width | 192.9 cm |
|---|---|
| Base depth | 2.97 cm |
| Base height | 110 cm |
| Base weight | 53 kg |
| Package width | 2100 mm |
|---|---|
| Package depth | 253 mm |
| Package height | 1250 mm |
| Package weight | 66.7 kg |
| Remote control included | Yes |
|---|---|
| Cables included | AC |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| LG technologies (AV/TV) | Auto Set ID, Booting Logo Image, Control Manager, Fail over, Gapless Playback, Group Manager, ISM Method, Local Contents Scheduling, Local Network Sync, No Signal Image, RS232C Sync, SI Server Setting, Setting Data Cloning, Smart Energy Saving, Status Mailing, Video Tag |
|---|
| Gyroscope | Yes |
|---|---|
| Temperature sensor | Yes |
| Ambient light sensor | Yes |
| Ethernet LAN | Yes |
|---|---|
| Wi-Fi | Yes |
| Wall mountable | Yes |
|---|
| Sustainability certificates | ENERGY STAR, EPEAT |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
