LG CreateBoard Standard interactive whiteboard 2.18 m (86") 3840 x 2160 pixels Touchscreen Black
Part number 86TR3DQ-B
86IN LCD 3840X2160 CREATEBOARD TOUCH HDMI USBC VGA
- Resolution : 3,840 × 2,160 (UHD)
- Brightness : 400 nit (Typ.)
- Multi-Touch Point : Max. 50 Points
- OS Ver. : Andorid 14 (EDLA)
- Interface (Input) : HDMI (3), DP, RGB (VGA), Audio, RS-232C, RJ45 (LAN), USB Type-C (2), USB 3.0 Type-A (5), USB 2.0 Type-A
- Interface (Output) : HDMI Out, Audio Out, Touch USB (3), RJ45 (LAN)
- Manufacturer
- LG
- Part number
- 86TR3DQ-B
- Condition
- New
- Category
- Displays › Large Format Displays
- 1GPA category
- Hardware
Overview
Innovate, Collaborate, and Create with Seamless Technology, LG CreateBoard
Creative Whiteboard Solution
LG CreateBoard offers a lifelike touch experience, allowing users to interact with content directly on the board. You can write, draw, zoom, and rotate using just your fingers, making it an effective tool for creative projects or presentations. Additionally, LG CreateBoard enables screen and content sharing, making it an excellent tool for seamless collaboration even with remote team members.
Various Teaching Templates
LG CreateBoard offers a variety of educational templates and tools such as a ruler, table, and sticky note, fostering active student participation and facilitating intuitive lessons.
Easy to Save / Import / Export
LG CreateBoard incorporates straightforward import and export features. Resources can be saved and directly imported to and from Google Drive or OneDrive. After meetings, you can directly send emails to share materials, or scan a QR code to transfer them to your personal device.
LG CreateBoard Lab
LG’s proprietary whiteboarding software
Tools for Fluid Discussion
A variety of tools such as a calculator, clock, and sticky note are available to facilitate smooth discussions and ensure seamless idea sharing and communication. Also, users can personalize the menu bar with their most frequently used tools, thereby improving their work efficiency.
Web Browser
When you need a reference during a discussion, you can access various online information in real time with the simple click of a web browser. The necessary information found on the internet can be easily dragged and dropped into the material you’re creating, enhancing the productivity of your meetings.
Multi-OS Support
LG CreateBoard Lab offers multi-OS support, allowing users to utilize it not only with LG CreateBoard but also with other devices. This enables users to maintain a seamless experience on tablets, laptops, and various other devices, even outside the classroom.
LG CreateBoard Share
LG CreateBoard Share offers a wireless screen sharing feature, providing users with a flexible discussion environment. Users can share their screen from their own PC, tablet, or smartphone, simplifying the process of sharing and collaborating on team projects or presentation materials.
Wireless ScreenShare Feature for Seamless Meeting Environment
LG CreateBoard Share establishes a seamless and stable meeting room without the need for extra cables or connections. Presenters can now share their screens without the need to inconveniently move around and unplug and plug cables each time the presenter changes. With the capability to share up to 9 screens in real-time, it’s possible to display multiple people’s materials simultaneously when needed, thereby enhancing the efficiency of collaboration.
Simple Connection to LG CreateBoard Share
Users can easily utilize the wireless screen sharing feature via LG CreateBoard Share app, and even without the app, they can still conveniently access this feature through the website. A quick connection to LG CreateBoard Share can be established by entering a 6-digit code.
Presentation Convenience and Flexibility in Meeting Room
Wireless screen sharing empowers presenters to navigate freely within a meeting room, unencumbered by cables. This feature enables them to seamlessly control their presentations directly from their own devices. In addition, they can conveniently send photos and videos stored on their personal devices, enhancing the fluidity and richness of their presentations.
Presentation Convenience and Flexibility in Classroom
In the classroom, the lecturer or presenter doesn’t need to conduct the lesson near the LG CreateBoard, but can flexibly conduct the lesson from anywhere in the classroom. This promotes a more flexible classroom environment and can help keep students more focused.
Secure Mode
LG CreateBoard Share supports Secure Mode, which allows users to grant permissions for sharing. Secure Mode prevents unauthorized users from sharing their screen.
LG ConnectedCare
LG ConnectedCare is a cloud solution for remotely monitoring, controlling, and managing the status of LG CreateBoard and LG signage displays. This feature enables IT managers to operate and manage important resources on operating devices without physically visiting sites.
Dashboard
Specifications
| Display diagonal | 2.18 m (86") |
|---|---|
| Display brightness | 400 cd/m² |
| Display number of colours | 1.07 billion colours |
| Display resolution | 3840 x 2160 pixels |
| Anti-glare screen | Yes |
| HD type | 4K Ultra HD |
| Panel type | IPS |
| LED backlight | Yes |
| LED backlighting type | Direct-LED |
| Native aspect ratio | 16:9 |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 5000:1 |
| Response time | 8 ms |
| Maximum refresh rate | 60 Hz |
| Touchscreen | Yes |
| Touch technology | Multi-touch |
| Number of simultaneous touchpoints | 50 |
| Touch system response time | 5 ms |
| Touch object size (min) | 2 mm |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Colour gamut | 72% |
| Screen glass thickness | 3.2 mm |
| Handles quantity | 1 |
| Operating system installed | Android |
|---|---|
| Operating system version | 14 |
| Built-in processor | Yes |
| Processor architecture | ARM Cortex A73 + ARM Cortex A53 |
| Maximum internal memory | 64 GB |
| RAM capacity | 8 GB |
| Graphics card family | ARM |
| Graphics card | Mali-G52 MP8 |
| Built-in speaker(s) | Yes |
|---|---|
| Speaker power | 40 W |
| Built-in subwoofer | Yes |
| Subwoofer RMS power | 20 W |
| Built-in projector | No |
|---|
| Wi-Fi | Yes |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Wake-on-LAN ready | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB connector type | Micro-USB A, USB Type-C |
| HDMI ports quantity | 3 |
| USB Type-C ports quantity | 2 |
| HDMI output ports quantity | 1 |
| RGB ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Line-in | Yes |
| OPS slot | 1 |
| S/PDIF out port | Yes |
| RS-232 ports | 1 |
| Product colour | Black |
|---|---|
| VESA mounting | Yes |
| Panel mounting interface | 800 x 600 mm |
| Wall mountable | Yes |
| Mean time between failures (MTBF) | 50000 h |
| Certification | IEC 62368-1:2018; UL 62368-1:2019 |
| Ambient light sensor | Yes |
|---|
| Power consumption (max) | 400 W |
|---|---|
| Power consumption (typical) | 235 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Windows operating systems supported | Yes |
|---|---|
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mobile operating systems supported | Android |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Width | 1957 mm |
|---|---|
| Depth | 99.7 mm |
| Height | 1170 mm |
| Weight | 54.1 kg |
| Bezel width (L/T, R/B) | 15/25.6/15/43.5 |
| Package width | 2110 mm |
|---|---|
| Package depth | 225 mm |
| Package height | 1291 mm |
| Package weight | 70.7 kg |
| Manual | Yes |
|---|---|
| Cables included | HDMI, Power, USB |
| Remote control included | Yes |
| Quick start guide | Yes |
| Stylus included | Yes |
| Sustainability certificates | ENERGY STAR, EPEAT, ErP |
|---|---|
| Compliance certificates | Federal Communications Commission (FCC) |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
