Products › Displays

LG

LG 86TR3BQ-B interactive whiteboard 2.18 m (86") 3840 x 2160 pixels Touchscreen Black

Part number 86TR3BQ-B

86IN CREATEBOARD NON-OS TOUCH 4K UHD 40PT IR HDMI 3YR WARR

  • Resolution : 3,840 x 2,160 (UHD)
  • Brightness : 350 nits (Typ.)
  • Multi-Touch : Max. 40 Points
  • Easy Connection & Sharing
  • User Friendly Experience
  • Security & Compatibility
Manufacturer
LG
Part number
86TR3BQ-B
Condition
New
Category
Displays › Tv Displays
1GPA category
Hardware

Overview

Seamless Writing Experience

LG CreateBoard delivers a lifelike touch experience with support for 4K resolution, enabling users to write seamlessly, ensuring every detail is crisp and clear.

Multi-Touch

LG CreateBoard boasts a multi-touch functionality that can concurrently detect up to 40 touch points. This feature facilitates simultaneous touch and gesture inputs from multiple users, fostering easy collaboration and idea sharing among team members. This enables efficient interaction in group activities or meetings.

Connect Your Own Device for OS Flexibility

LG CreateBoard integrates smoothly with devices across various operating systems, including Windows, Android, and ChromeOS, allowing users to work within their preferred environments. This creates a flexible and highly adaptable workspace tailored to individual needs.

C-Type Connection

USB-C connectivity simplifies connections which enables charging and sending data simultaneously over just one single cable.

OTA (Over-The-Air) Functionality

OTA (Over-The-Air) functionality built into the LG CreateBoard enables software updates to be performed wirelessly and automatically, allowing users to maintain the latest features and security patches.

Front Connectivity Design

LG CreateBoard is designed with front display ports, making it easy for users to connect or disconnect cables.

Built-In OPS Slot

LG CreateBoard supports OPS slots, allowing users to conveniently mount OPS Module at the back of the screen without the hassle of connecting to an external desktop. This enables various PC functions and Windows software.

Specifications

Display
Display diagonal2.18 m (86")
Display brightness350 cd/m²
Display resolution3840 x 2160 pixels
HD type4K Ultra HD
Panel typeIPS
LED backlightYes
LED backlighting typeDirect-LED
Contrast ratio (typical)1200:1
Response time8 ms
TouchscreenYes
Touch technologyMulti-touch
Touchscreen typeInfrared
Number of simultaneous touchpoints40
Touch system response time10 ms
Viewing angle, horizontal178°
Viewing angle, vertical178°
Accuracy touch1.5 mm
Audio
Built-in speaker(s)Yes
Number of built-in speakers2
Speaker power16 W
Projector
Built-in projectorNo
Network
Ethernet LANYes
Ports & interfaces
USB 2.0 ports quantity1
USB 2.0 Type-A hub ports quantity4
HDMI ports quantity3
USB Type-C ports quantity1
HDMI output ports quantity1
RGB ports quantity1
Ethernet LAN (RJ-45) ports1
S/PDIF out portYes
RS-232 ports1
Ergonomics
Product colourBlack
VESA mountingYes
Panel mounting interface800 x 600 mm
CertificationCB / NRTL, FCC Class "A" / CE / KC, ErP
Power
Power consumption (max)437 W
Power consumption (typical)203 W
Power consumption (off)0.5 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
System requirements
Windows operating systems supportedYes
Mac operating systems supportedYes
Linux operating systems supportedYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90%
Weight & dimensions
Width1957 mm
Depth97 mm
Height1160 mm
Weight51 kg
Packaging data
Package width2110 mm
Package depth225 mm
Package height1283 mm
Packaging content
ManualYes

Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
