LG 75XF3C-B Signage Display Digital signage flat panel 190.5 cm (75") LED 3000 cd/m² 4K Ultra HD Black 24/7
Part number 75XF3C-B
75IN 3840X2160 LCD OPEN FRAME 3000NIT HDMI DP DVI M+ ETA MARCH
- Digital signage flat panel Black
- 190.5 cm (75") 3840 x 2160 pixels LED 3000 cd/m²
- 8 ms
- Ethernet LAN
- Manufacturer
- LG
- Part number
- 75XF3C-B
- Condition
- New
- Category
- Displays › Large Format Displays
- 1GPA category
- Hardware
Overview
High Operationing Temperature
Its high reliability under high operating temperatures reduces the material costs of the enclosure.
Dust & Humidity Protection
The conformal coating enhances circuit board reliability by protecting it from dust, iron shavings, humidity and other harsh conditions.
Increased Brightness
The brightness has been increased to 3,000 cd/m2 compared to previous models
Wide Viewing Angle
IPS technology provides better control of the liquid crystals which allows the screen to be viewed from virtually any angle.
Color Accuracy
IPS technology displays accurate color for each pixel closest to the original image and reproduces the original color without distortion.
No Blackening Effect
Even under direct sunlight exposure, LG commercial monitors remain free of blackening defects under 110°C and provide superior quality for outdoor usage.
Low Power Consumption Using The M+ Panel
The M+ panel offers excellent energy efficiency and cost savings and decreases power consumption by 30 compared to conventional RGB panels.
Smart Brightness Control
The auto-brightness sensor and preset time scheduler save power whenever possible.
Slimmer Depth
The slimmer depth saves space for installation and makes the enclosure design slimmer.
Real-Time Remote Monitoring
When an alarm occurs, an email notification is sent through the SNMP using the SuperSign C or SI software. In case a malfunction or error occurs, real-time remote care is available.
Saving System Log Files
The XF3C supports log file back-up for fault clarification when the display fails. This allows you to conveniently check when an error has occurred.
Specifications
| Display diagonal | 190.5 cm (75") |
|---|---|
| Display technology | LED |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 3000 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display diagonal (metric) | 189 cm |
| Panel life | 50000 h |
| Horizontal scan range | 30 - 135 kHz |
| Vertical scan range | 30 - 60.3 Hz |
| HDMI ports quantity | 2 |
|---|---|
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| DisplayPorts quantity | 2 |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| RS-232 interface | Yes |
| RS-232C | Yes |
| Card reader integrated | Yes |
| Compatible memory cards | SD |
| Built-in speaker(s) | No |
|---|
| Product design | Digital signage flat panel |
|---|---|
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Bezel width (bottom) | 1.28 cm |
| Bezel width (side) | 1.18 cm |
| Bezel width (top) | 1.18 cm |
| TV tuner integrated | No |
|---|---|
| Operating hours (hours/days) | 24/7 |
| Power consumption (typical) | 750 W |
|---|---|
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Width | 1675.2 mm |
|---|---|
| Depth | 123.9 mm |
| Height | 953.6 mm |
| Weight | 36.7 kg |
| Remote control included | Yes |
|---|---|
| Cables included | AC, DVI, DisplayPort, HDMI, IR sensor |
| Operating temperature (T-T) | 0 - 50 °C |
|---|
| Harmonized System (HS) code | 85285210 |
|---|
| Ethernet LAN | Yes |
|---|
| Manual | Yes |
|---|---|
| RS-232 input ports | 1 |
| RS-232 output ports | 1 |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
