LG 75UH5Q-E Signage Display Digital signage flat panel 190.5 cm (75") Wi-Fi 500 cd/m² 4K Ultra HD Black WebOS 24/7
Part number 75UH5Q-E
75IN LCD 3840X2160 4K 24/7 MNTR HDMI DP WEBOS8.0 500NIT LAND/PORT
- Resolution : 3,840 × 2,160 (UHD)
- Brightness : 500 nits (Typ.)
- Bezel Width : 12.9 mm (Even)
- webOS Smart Platform
- LG Shield
- Manufacturer
- LG
- Part number
- 75UH5Q-E
- Condition
- New
- Category
- Displays › Touchscreen Monitors
- 1GPA category
- Hardware
Overview
Large UHD Signage Display with LG webOS Platform and Advanced Security
Superb Picture Quality with Ultra HD Resolution
With the resolution of UHD, it makes the colors and details of the content vivid and realistic. In addition, the wide viewing angle provides clear content.
Convenient webOS Platform
The UH5Q is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, and includes webOS partner apps to create an SI-friendly environment.
Durability that Provides Reliability
Optimized for business environments, the UH5Q is protected against salt, dust, iron powder and humidity thanks to conformal partial coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x and Shock Monitoring*, provide both reliability and satisfaction.
Comprehensive Security
webOS Signage goes beyond security measures at the operating system (OS) level. LG Shield employs a five-tiered defense system, encompassing server, application, operating system, system, and hardware. Each layer operates independently, providing comprehensive protection against various threats. Also, the webOS platform supports ETSI EN 303 645.
SuperSign Solutions
SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
Specifications
| Panel type | ADS |
|---|---|
| LED backlight | Yes |
| LED backlighting type | Edge-LED |
| Display diagonal | 190.5 cm (75") |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 1000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Panel life | 50000 h |
| Supported graphics resolutions | 3840 x 2160 |
| Supported video modes | 2160p |
| Native refresh rate | 60 Hz |
| Haze rate | 25% |
| Colour gamut | 95% |
| HDMI ports quantity | 3 |
|---|---|
| Consumer Electronics Control (CEC) | Yes |
| DVI port | No |
| DisplayPorts quantity | 1 |
| USB port | Yes |
| USB ports quantity | 2 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232C | Yes |
| Built-in speaker(s) | Yes |
|---|---|
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Product design | Digital signage flat panel |
|---|---|
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Bezel width (bottom) | 1.29 cm |
| Bezel width (side) | 1.29 cm |
| Bezel width (top) | 1.29 cm |
| Bezel colour | Black |
| Mounting type | Wall |
| Purpose | Commercial |
|---|---|
| Picture-in-Picture | Yes |
| Digital Rights Management (DRM) type | Pro:Idiom |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Multi |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| Automatic brightness control | Yes |
| International Protection (IP) code | IP5X |
| HDCP version | 1.4/2.2 |
| webRTC support | Yes |
| Power consumption (typical) | 160 W |
|---|---|
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.5 W |
| Power consumption (max) | 247 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Heat generation (typical) | 546 BTU/h |
| Heat generation (max) | 843 BTU/h |
| Computer system | Yes |
|---|---|
| Computer system type | System on Chip (SoC) |
| Internal memory | 16 GB |
| Operating system installed | WebOS |
| Operating system version | 8.0 |
| Display width | 1679.5 mm |
|---|---|
| Display depth | 29.7 mm |
| Display height | 958.7 mm |
| Display weight | 35.7 kg |
| Package width | 1820 mm |
|---|---|
| Package depth | 200 mm |
| Package height | 1115 mm |
| Package weight | 44 kg |
| Remote control included | Yes |
|---|---|
| Cables included | Power |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| LG technologies (AV/TV) | Control Manager, Gapless Playback, ISM Method, SI Server Setting, Local Contents Scheduling, Booting Logo Image, Auto Set ID, Group Manager, No Signal Image, Setting Data Cloning, Status Mailing, Smart Energy Saving |
|---|
| Gyroscope | Yes |
|---|---|
| Temperature sensor | Yes |
| Ethernet LAN | Yes |
|---|---|
| Wi-Fi | Yes |
| Security algorithms | SNMP |
| Wake-on-LAN | Yes |
| Compliance certificates | CB, Electromagnetic Compatibility (EMC), Federal Communications Commission (FCC), CE, KC |
|---|
| Quick start guide | Yes |
|---|---|
| Bluetooth | Yes |
| Power consumption (PowerSave) | 112 W |
| Plug and Play | Yes |
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
