LG 55XF3E-B Signage Display Digital signage flat panel 139.7 cm (55") LCD 3000 cd/m² Full HD Black WebOS 24/7
Part number 55XF3E-B
55IN LCD 1920X1080 OPEN FRAME 3000NIT WEBOS HDMI 24/7 LAND/PORT
- Indoor/outdoor Digital signage flat panel Black
- 139.7 cm (55") 1920 x 1080 pixels LCD 3000 cd/m²
- Ethernet LAN
- Manufacturer
- LG
- Part number
- 55XF3E-B
- Condition
- New
- Category
- Displays › Large Format Displays
- 1GPA category
- Hardware
Overview
High Brightness
With a great brightness of 3,000 cd/㎡, XF series clearly deliver contents and attract public attention, which is the ultimate display for outdoor visibility.
Visible with Polarized Sunglasses
Quarter Wave Plate enables clear visibility even when the viewer is wearing polarized sunglasses.
No Blackening
Even under direct sunlight exposure, the open frame XF series remain free of blackening defects under 110°C and provide superior quality for outdoor usage.
Smart Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.
High Operating Temperature
Its high reliability under high operating temperatures reduces additional costs for air conditioning system.
Conformal Coating
The product can be often unavoidably exposed to dust and water during maintenance. Conformal coating on every major circuit board eliminates such troubles by protecting it against dust, iron powder, humidity, etc.
High-Performance with webOS Smart Platform
Quad Core SoC can execute several tasks at the same time without a separate media player. In addition, webOS 3.0 platform enhances user convenience with intuitive UI and simple app develoment tools.
Slim Design
Thanks to its thin depth, the XF series takes up less space and leads to ease of installation for various applications.
Specifications
| Display diagonal | 139.7 cm (55") |
|---|---|
| Display technology | LCD |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 3000 cd/m² |
| HD type | Full HD |
| Touchscreen | No |
| Native aspect ratio | 16:9 |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Panel life | 50000 h |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| HDMI ports quantity | 2 |
|---|---|
| DVI port | Yes |
| DVI-D ports quantity | 1 |
| DisplayPorts quantity | 2 |
| USB port | Yes |
| USB ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| PC Audio in | Yes |
| Number of speaker outputs | 1 |
| RS-232C | Yes |
| Remote (IR) input | 1 |
| Built-in speaker(s) | No |
|---|
| Product design | Digital signage flat panel |
|---|---|
| Placement supported | Indoor/outdoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 600 x 400 mm |
| Bezel width (bottom) | 1.2 cm |
| Bezel width (side) | 9.9 mm |
| Bezel width (top) | 1.2 cm |
| Purpose | Universal |
|---|---|
| Operating hours (hours/days) | 24/7 |
| Power consumption (typical) | 250 W |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Computer system | Yes |
|---|---|
| Computer system type | System on Chip (SoC) |
| Operating system installed | WebOS |
| Width | 1235.5 mm |
|---|---|
| Depth | 106.8 mm |
| Height | 709.4 mm |
| Weight | 26.5 kg |
| Package width | 1344 mm |
|---|---|
| Package depth | 236 mm |
| Package height | 820 mm |
| Package weight | 32.2 kg |
| Remote control included | Yes |
|---|---|
| Batteries included | Yes |
| Cables included | AC, HDMI |
| Operating temperature (T-T) | 0 - 50 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Certification | FCC Class "A" / CE / KC / VCCI / UL Recognized / CB |
|---|
| Harmonized System (HS) code | 85285210 |
|---|
| Ethernet LAN | Yes |
|---|
| Quick start guide | Yes |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
