LG 55EW5Q-C Signage Display Digital signage flat panel 139.7 cm (55") OLED Wi-Fi 600 cd/m² Full HD Black WebOS 18/7
Part number 55EW5Q-C
55IN TRANSPARENT OLED 1920X1080 HDMI DP RS-232C RJ45 WEBOS7.5
- Brightness : 200 / 600 nit (APL 100% / 25%, without Glass)
- Native Resolution : 1,920 × 1,080 (FHD)
- Contrast Ratio : 200,000 : 1
- Manufacturer
- LG
- Part number
- 55EW5Q-C
- Condition
- New
- Category
- Displays › Large Format Displays
- 1GPA category
- Hardware
Overview
High Transparency
LG’s OLED technology enables the Transparent OLED Signage to have a sleek design without the need for a backlight unit or liquid crystal layer, achieving an impressive 43%* transparency. It clearly displays objects behind the screen while overlaying relevant information right in front of them.
Protective Tempered Glass
Touching a display directly can cause damage or scratches. The tempered glass in front protects the product from such external impacts and its anti-shatter glass is designed to help minimize customers' injuries.
Sleek Elegance in Transparency
By connecting spaces and creating a sense of openness, this transparent display features a stunning design that enhances high-end furniture and luxurious interiors. It is designed as a semi-assembled display, allowing for versatile installation options to seamlessly integrate into existing structures and spaces.
Specifications
| LED backlight | Yes |
|---|---|
| Display diagonal | 139.7 cm (55") |
| Display technology | OLED |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 600 cd/m² |
| HD type | Full HD |
| Touchscreen | No |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 200000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.07 billion colours |
| Panel life | 50000 h |
| Native refresh rate | 60 Hz |
| Haze rate | 3% |
| HDMI ports quantity | 1 |
|---|---|
| HDMI input ports quantity | 1 |
| DisplayPorts quantity | 2 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| USB port | Yes |
| USB ports quantity | 2 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| Ethernet LAN (RJ-45) ports | 2 |
| RS-232C | Yes |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| Product design | Digital signage flat panel |
|---|---|
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| VESA mounting | Yes |
| Bezel width (bottom) | 12.2 cm |
| Bezel width (side) | 7.9 mm |
| Bezel width (top) | 7.9 mm |
| Purpose | Universal |
|---|---|
| On Screen Display (OSD) | Yes |
| Operating hours (hours/days) | 18/7 |
| Power consumption (typical) | 70 W |
|---|---|
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 230 W |
| Energy efficiency class (SDR) | F |
| Energy efficiency class (HDR) | Not available |
| AC input voltage | 100-240 V |
| AC input frequency | 50/60 Hz |
| Internal memory | 16 GB |
|---|---|
| Operating system installed | WebOS |
| Operating system version | 7.5 |
| Display width | 1225.5 mm |
|---|---|
| Display depth | 14.6 mm |
| Display height | 810.1 mm |
| Display weight | 11.6 kg |
| Base width | 38.2 cm |
| Base depth | 7.36 cm |
| Base height | 21.8 cm |
| Base weight | 2.6 kg |
| Package width | 1345 mm |
|---|---|
| Package depth | 246 mm |
| Package height | 920 mm |
| Package weight | 21.9 kg |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 80% |
| Ethernet LAN | Yes |
|---|---|
| Wi-Fi | Yes |
| Power supply type | Internal |
|---|
Product photos and overview provided by the manufacturer through Icecat. Confirm specifications with your rep before ordering.
